Operator’s manual
Bale wrapper
Spin
- 3 -
3. TECHNICAL DESCRIPTION
3.1. Technical data
Tab. 1. Specification of bale wrapping machine
Designation Unit Spin
Coupling with the tractor - Suspended
Overall dimensions
Length/Width/Height
ft. in 8' 8"/4' 8"/5' 5"
Machine weight lbs 204.12
Maximum bale weight lbs 362.87
Wrapped bale dimension
Length
Diameter
ft. in
3' 11"
3' 3"-3' 11"
Maximum transport speed mph 12
Coupling with tractor through : - Three point hitch
Tractor class - 0.9
Minimum tractor power output kW 30
Required pressure in the tractor
power hydraulics system
MPa 14
Recommended tractor pump
output
l/min 22
Wrapping machine drive -
Hydraulic, from the tractor's power
hydraulics system
Rotary frame drive - Hydraulic motor
Maximum rotation speed of the
rotary frame
rpm 35
Bale loading method -
Lift with a lifting capacity of at least
1000 kg
Bale unloading method - Automatic, with a tilting frame
Film width ft. in 1' 8"; 2' 6"
Number of rotary frame
revolutions using film :
1' 8"
2' 6"
rpm
24
16
Bale wrapping time min ~2
Number of operators - 1 ( tractor driver )
Wrap counter - Electronic, type L-01
Electrical system voltage V 12
Machine lighting - optional -
Following the requirements of the road
code
