Operator’s manual
Bale wrapper
Spin
- 11 -
5. DRIVE OPERATION
5.1. Drive coupling
The bale wrapping machine should be coupled with tractors with rated power not lower than
30kW and traction class 0.9 equipped with a three point hitch.
It is advised to couple the wrapping machine with tractors equipped with a front axle ballast.
WARNING!
Make sure that there are no bystanders especially children, in the coupling
area.
During coupling the equipment to the tractor, place the machine in the tractor‘s axis on flat,
level ground. Engage the tractor‘s parking brake. Couple the machine with a three point hitch.
WARNING!
Check if the coupling is properly connected and secured against accident
disconnection.
WARNING!
Make sure that the tractor‘s hydraulic system is sealed.
Connect the electric power source. Check if the electric and signalizing systems work
properly.
Load the first bale and make sure that the vertical load on the tractor’s front axle is larger
than 20% of the tractor’s weight. The tractor should remain fully steerable.
5.2. Disconnecting the drive
NOTE!
Make sure that there are no bystanders, especially children, in the wrapping
machine’s storage area and its vicinity.
Place the raised wrapping machine over the supports prepared earlier.
Using the tractor‘s three point hitch gently lower the wrapping machine on the supports.
Make sure that the machine will not move accidentally.
Disconnect the electric power supply and the hydraulic system.
Disconnect the wrapping machine from the three point hitch.
6. COMMISSIONING
The commissioning of a newly purchased bale wrapping machine should be performer under
the supervision of an experienced operator or a dealer’s service representative.
NOTE!
Before commissioning, familiarize yourself with the following manual,
paying special attention to the fragments regarding the safety of the operator
and bystanders.
