SAMCHULLY SD - Page 15

15
Instruction Manual
Instruction Manual
형식 / Type / 型式
A(F7) B C D E(Max.)
후면체결 볼트
Rear Mounting Bolt
后安装螺栓
SD-13546
100
65 147
5 10
6-M8x95L
SD-15452 130 70 170 5 17 6-M8x85L
SD-17568 160 85 190 5 20 6-M10x100L
SD-18577 160 95 200 5 20 6-M8x110L
SD-18582 160 100 205 5 20 6-M10x110L
SD-20591 180
110
227 5
25 6-M10x120L
SD-21510 200 125 240 5 30 6-M12x120L
SDL-25411 230 140 275 6 40 8-M12x140L
SDL-30516 260 190 345 5 46 12-M12x160L
SD-13546S 100 65 147 5 10 6-M8x100L
SD-15452S 130 70 170 5 17 6-M8x85L
SD-17568S 160 85 190 5 20 6-M10x100L
SD-18546S 160 65 205 5 24 6-M10x105L
SDL-21546S 180 65 240 5 24 6-M12x115L
Keep the run-out on cylinder adaptor front
face and the run-out on its inside diameter
both within 0.005mm. Excessive run-out
can cause vibration and shorten the
cylinde
r’
s life span.
실린더 아답터의 전면 흔들림 및 기준경(부착
부)의 흔들림은 0.005mm 이하로 되게 부착
하여 주십시오. 흔들림이 클 경우 진동 및 흔들
림 불량의 원인이 되고, 실린더의 수명을 단축
시킵니다.
󲶽󸃓󴀿󾖺󾖴 󴫿󶵞󸵳󹀢󽖒󵵙󱴙󹪸󳴵󱶴󲃅󲙨󱱅
󵸌󳔨󾖸󲶽󸃓󸽨󱟹󾖹󵵙󳴵󱶴󳍟󱙚󾖼
󱝤󱘕󷔐󳴵󱶴󶌰󳍾󸳣󲡱󽘜󱞴󳑘󾖴 󸤐󹧮
󱶴󽘜󱞴󶵌󵾪󴫿󶵞󲺱󲂰
IMPORTANT
IMPORTANT
유의사항
IMPORTANT
危 险
