SAMIX ES500 - Switching off and Removing the Mixing Unit

31
SAMIX GmbH
Operation
6.5.2 Switching off and removing the mixing unit
ATTENTION
Risk of material damage!
Remove the mixing unit downwards from the oscillation arm in order to avoid damage to the
oscillation arm or the mixing shaft.
NOTICE
After the mixing unit has been removed from the oscillation arm, it is useful to turn the mixing
unit in an anticlockwise direction in order to remove the mixing blade from the bayonet mount.
2
1
Fig. 17: Unscrew the mixing unit from the oscillation arm and remove mixing unit
If necessary, switch off the power switch.
NOTICE
In the event of a prolonged period of non-usage, it is recommended to switch off the SAMIX
®
ES500.
