3-12 EB 8052-E EN
Design and principle of operation
Dimensional drawings
Type 3271 Pneumatic
Actuator
Type 3271 Pneumatic
Actuator
Type 3277 Pneumatic
Actuator
Type 3277 Pneumatic
Actuator
H4H2
L
H8
H9
G
H4H2
L
H8
H9
G
H4H2
L
H8
H9
H5
G
H4H2
L
H8
H9
H5
G
Type3251-E-1
Up to NPS4 without foot
Type3251-E-1
NPS6 and larger with
foot
Type3251-E-7
Up to NPS4 without foot
Type3251-E-7
NPS6 and larger with
foot
Refer to the following data sheet for more dimensions and weights:
uT8052-E
The associated actuator documentation applies to actuators, e.g. for SAMSON pneumatic
actuators:
uT8310-1 for Type3271 or Type3277 Pneumatic Actuators up to 750cm² actuator area
uT8310-2 for Type3271 Actuator with 1000cm² actuator area and larger
uT8310-3 for Type3271 Actuator with 1400-60cm² actuator area
Note
