EB 8015 EN 5-7
Installation
301
301
309
309
9
303
304
114
Y
1
-
0
0,5
Y
1
-
0
0,5
Legend
9 Stem
114 Lubricant Gleitmo 1763V
301 Clamps
303 Screws
304 Washers
309 Sliding washers
Plug stem
Fig.5-3: Overview of anti-rotation xture assembly
