Resolv 40a Rear Control Panel
The Resolv 40a’s rear control panel is where you will make your connections for both AC power and audio sig-
nals. The following section details the rear panel controls and connections.
Powering the Resolv 40a
Since the Resolv 40a is an active studio monitor with an on-board power amplifier, it is necessary to connect the unit to
an AC power supply. Make sure that the main Power switch is set to the off position and connect the supplied IEC power
cable into the AC inlet.
Things that go Hum!
When running power cables, be careful not to run the AC power cords or AC extension cords in parallel to
your input cables. This will help reduce any AC hum that can be picked up. If your have to cross an AC line with
an audio line, try to cross them at a 90 degree angle for the least amount of induced hum.
POWER SWITCH
– The POWER switch is used to turn on the Resolv 40a’s active electronics. When set to
the on position, the front panel blue
LED illuminates, indicating the Resolv
40a is powered up and ready for
operation.
AC INLET
- Connect the supplied IEC
power cable here.
