Appendix A (conguration instructions)
Risk of damage of the heating circuit due to lightning or overvoltage.
Î Upon installation, observe the relevant standards and regulations governing lightning
and overvoltage protection.
Functions Default Conguration
Modbus 1 CO6->F01-1
16-bit address 0 CO6->F02
Monitoring 0 CO6->F07
Parameters
1)
Default Parameter level: value range
Station address (ST) 255 PA6: 1 to 247
WithCO6->F02-1:1to32000
Description of communication parameter settings
− Station address (ST)
This address is used to identify the controller in bus or modem mode. In a system, each
controller needs to be assigned a unique address.
16.5.2 Memory module/mini module
Theuseofamemorymoduleorminimodule(seeAppendixB)isparticularlyusefultotrans-
feralldatafromoneTROVIS5573ControllertoseveralotherTROVIS5573Controllers.
In contrast to the memory module, the mini module is not suitable for transferring the pro-
grammed vacations to the individual control circuits or a data logging conguration pro-
grammed in TROVIS-VIEW.
Thememorymodule/minimoduleispluggedintotheRJ-45connectorsocketlocatedatthe
sideofthecontroller.Oncethemodulehasbeenconnected,'73SP'appearsonthecontrol-
lerdisplay.IfthememorymodulealreadycontainsdatafromadifferentTROVIS5573Con-
troller,turntherotarypushbuttonuntil'SP73'isdisplayed.
