EB 5573 EN 16-79
Appendix A (conguration instructions)
− Pressingtherotarypushbuttontoconrm'73SP'causesthecontrollersettingstobe
transferredtothememorymodule/minimodule.
− Pressingtherotarypushbuttontoconrm'SP73'causesthecontrollersettingstobe
transferredfromthememorymodule/minimodule.
While the data is being exchanged, bars run across the display. When the transfer is com-
pleted, 'I.O.' is displayed. After that, the connection between controller and memory mod-
ule/minimodulecanbeterminated.
TROVIS-VIEWallowsuserstocongureallcontrollersettingsonaconvenientuserinterface
at the computer and to document these settings.
16.5.3 Data logging
Adataloggingmodule(seeAppendixB)savesthefollowingcontrollerdataeverytwomin-
utes:
− Temperatures measured by the sensors
− Controlsignalsin%
− Switching states of the pump outputs
The data logging module is plugged into the RJ-45 connector socket located at the side of the
controller.
The controller starts to write over the oldest data as soon the memory of the data logging
module is full after approximately eight days. The current memory capacity of the data log-
ging module can be read in the extended information level under InFo 2 as the second value
in the sequence (range of values: 0 to 6035). Directly after inserting the data logging mod-
ule,datacanberstreadaftertherstscanningcyclehasbeenperformed.
The data log viewer software allows the data to be viewed in graph format. The USB convert-
er3(seeAppendixB)isrequiredtoconnectthedataloggingmoduletoacomputer.Theda-
ta log viewer software is supplied together with the USB converter 3.
