EB 5573 EN 8-3
Setup
8.2.2 Setting the times-of-use
Three times-of-use can be set for each day of the week.
Parameters Default
1)
Value range
Period/day 1-7 1-7,1,2,3,4,5,6,7with1-7daily,1=Monday,2=
Tuesday,…,7=Sunday
Startrsttime-of-use 06:00 00:00to24:00h;instepsof15minutes
Stoprsttime-of-use 22:00 00:00to24:00h;instepsof15minutes
Start second time-of-use 22:15 00:00to24:00h;instepsof15minutes
Stop second time-of-use 22:15 00:00to24:00h;instepsof15minutes
Start third time-of-use --:-- 00:00to24:00h;instepsof15minutes
Stop third time-of-use --:-- 00:00to24:00h;instepsof15minutes
1)
Default settings applicable to the heating circuits
How to proceed:
1. Turn the rotary switch to
(times-of-use).
blinks.
Insystemswithonlyonecontrolcircuit(e.g.systemAnl1.0),steps2to5(toselectthe
controlcircuitandconguretheDHWcircuit)arenotrequired.
InsystemsAnl1.5and1.9,onlytheDHWcircuitiscontrolled.Asaresult,steps2and3
(to select the control circuit) are not required.
2. Select the control circuit for which the time-of-use is to be programmed.
1: Heating circuit 1
2: Heating circuit 2
3:DHWheating/circulationpump
Only those control circuits are available for selection which can be controlled by the se-
lected system.
3. Conrmtheselectedcontrolcircuit[Û].
If control circuit 1 or 2 has been selected, steps 4 and 5 are not required.
4. CongureDHWcircuit[q]:
DHW heating Circulation pump (DHW)
5. Conrmsetting[Û].
