Design and principle of operation
Pneumatic positioner
Type 3766- xxx01xxxx1x0x0
Pneumatic connections
¼-18 NPT
1
ISO 228/1 - G ¼
2
Electrical connections
Without (no additional equipment or solenoid valve)
00 00
Cable gland
M20 x 1.5, blue (plastic)
10 0
M20 x 1.5, black (plastic)
20 0
M20 x 1.5 (nickel-plated brass)
21 3
Housing version
Die-cast aluminum
0
Stainless steel (CrNiMo)
2
Temperature range
Standard
0
Low temperature
T
min
³
–50 °C; optional limit switches, solenoid valve
21 3
Special version
Without
000
GOST Ex approval 0Ex ia IIC T8 X
1
010
* Available until March 2011
Device functioning only as analog position transmitter: 3766-x60 000xxx00 000 0
