4 Troubleshooting
4-1
4 Troubleshooting
4-1 No Power
Does proper DC 15V/5V
appear at Pin 1,6,7,8 CN505?
Check connector Pin3,6,7,8 in
I/P Board.
Does proper DC 1.8V
appear at Pin 5 of IC405?
Check 5V appear at Pin 2 of
IC405
Check IC302
Does proper DC 3.3V
appear at Pin 2 IC404?
Check 5V at Pin1 of IC404
and Pin2 of IC403
To Next Page
