Samsung 741MP - Pin Assignments

14 Reference Infomation
14-8
14-4 Pin Assignments
Sync
Type
Pin No.
15-Pin Signal Cable Connector
Separate Composite
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red
Green
Blue
GND
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
DDC +5V
CHK D_SUB
GND
DDC Data
Horizontal sync
Vertical sync
DDC Clock
Red
Green
Blue
GND
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
DDC +5V
CHK D_SUB
GND
DDC Data
H/V-Sync
Not Used
DDC Clock
