6 Electrical Parts List
6-1
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
LS17DOASS/EDC 741MP,SAE1/S17AZ-LDO,17,LCD-MO,NETHERLAN
0.1 M0216 BN90-00814A ASSY STAND;LS19DOWSS/XAA,DO19WS 1 S.N.A
..2 STD BN96-02966A ASSY STAND P-BODY;LS19DOW,HIPS HB,BK24,Z 1 S.A
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 4 S.N.A
...3 BN63-02128A COVER-STAND FRONT;LS19DOW,HIPS,T2.5,HB,B 1 S.N.A
...3 BN63-02129A COVER-STAND REAR;LS19DOW,HIPS,T2.5,HB,BK 1 S.N.A
...3 T0054 BN96-02967A ASSY HINGE P;LS19DOW,ZNDC 1 S.N.A
0.1 M0001 BN90-01008A ASSY COVER FRONT;DVORAK 17,4:3 1 S.N.A
..2 T0003 BN96-03869B ASSY COVER P-FRONT;DVORAK 17",ABS HB,GR7 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.N.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 S.N.A
...3 T0069 AA60-00171E SPACER-FELT;43L2,FELT,300,T0.5,5 4 S.N.A
...3 M0112 BN63-02681A COVER-FRONT;DVORAK,ABS,HB,GR70 1 S.N.A
...3 T0059 BN64-00506A INDICATOR LED;DVORAK,ACRYL,CLR 1 S.N.A
...3 T0022 BN64-00507A KNOB-CONTROL;DVORAK,ABS,HB,GR70 1 S.N.A
...3 T0175 BN96-00515C ASSY SPEAKER P;8ohm,Dvorak 17",2W,2pin,4 1 S.N.A
...3 T0175 BN96-00518B ASSY SPEAKER P;16ohm,Dvorak, 17,Right,2W 1 S.N.A
...3 M0145 BN96-03847A ASSY BOARD P-FUNCTION IR;DVORAK,SJ06-01- 1 S.N.A
0.1 M0002 BN90-01009A ASSY COVER REAR;DVORAK 17,4:3 1 S.N.A
..2 M0013 BN96-03871A ASSY COVER P-REAR;DVORAK 17",HIPS HB,BK2 1 S.A
...3 M0113 BN61-01581A BRACKET-VESA;BI17/19BS,SECC,T1.0 2 S.N.A
...3 M0006 BN63-02682A COVER-REAR;DVORAK,HIPS,HB,BK24 1 S.N.A
0.1 M0106 BN91-00841H ASSY LCD-STZ;PO24FS 1 S.N.A
..2 M0215 BN07-00206A LCD-PANEL;LTM170EX-L21,Bizet,6BIT FRC,35 1 S.A
0.1 M0017 BN91-01132A ASSY CHASSIS-STZ;LS17DOASS/EDC 1 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,S,M4,L8,ZPC(YEL) 1 S.N.A
..2 BN61-02577A HOLDER-JACK;DVORAK,ABS,BK24,V0 1 S.N.A
..2 T0376 BN63-02134A SHIELD-VIDEO;LS19DOW,SPTE,T0.2 1 S.N.A
..2 M0014 BN94-01039A ASSY PCB MAIN-STZ;LS17DOASS/EDC 1 S.N.A
...3 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45§-,96.5Sn/ 0.599 S.N.A
...3 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ 0.003 S.N.A
...3 CN100 3701-001219 CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN300 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
...3 CN500 3722-000183 JACK-SCART;21P,SN,BLK 1 S.A
...3 CN501 3722-002081 JACK-EAR PHONE;5P/2C,-,SnPb,L-BLU,- 1 S.A
...3 JA333 3722-002267 JACK-PIN;3P,AU,RED/WHT/YEL,ANGLE 1 S.A
...3 CN200 3722-002275 JACK-DIN;4P,-,SN,BLK,- 1 S.A
...3 CIS3 BN40-00093A TUNER;VFT-6C/W235S,VFT-6C/W235S,PAL B/G, 1 S.A
...3 MAIN BN97-01100A ASSY MICOM-MAIN;LS17DOASS/EDC,W/W 1 S.N.A
....4 IC115 1107-001580 IC-FLASH MEMORY;MX25L4005,4Mbit,512Kx8Bi 1 S.N.A
...3 T0174 BN97-01101A ASSY SMD;LS17DOASS/EDC 1 S.N.A
....4 D100 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D201 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D516 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D517 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D518 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D519 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D523 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D300 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
6 Electrical Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LS17DOA Parts List
To Next Page
