3. Installing the Product

English 8/2020. Rev 0.3 81

4. Connect the signal cable “WIRE ASSY MODULE TO MODULE #1" from Module #3 “Left Connector” to

Module #4 “Right Connector.”

Figure 3-96: Module #3 to Module #4 Signal Cabling

5. Connect the signal cable “WIRE ASSY MODULE TO MODULE #1" from Module #4 “Left Connector” to

Module #5 “Right Connector.”

Figure 3-97: Module #4 to Module #5 Signal Cabling
