Installation Procedure
6 View mode: When the K4 switch is pressed, you can see information about our system state as below.
K4
short
push
Display contents SEG1 SEG2 SEG3 SEG4 Unit
1 Order frequency 1 Hundreds digit Tens digit Units digit Hz
2 Current frequency 2 Hundreds digit Tens digit Units digit Hz
3
The number of preset indoor
units
3 Hundreds digit Tens digit Units digit EA
4
Ambient temperature sensor 4 + / - Tens digit Units digit °C
5
Compressor discharge sensor 5 Hundreds digit Tens digit Units digit °C
6 Eva-Mid sensor 6 + / - Tens digit Units digit °C
7 Condensor sensor 7 + / - Tens digit Units digit °C
8 Current 8 Tens digit Units digit
Ɵ˵ʪѣθϑϩΧɇʀʪͱ˙
decimals
A
9 Outdoor fan RPM 9 Thousands digit Hundreds digit Tens digit rpm
10
Target discharge
temperature
A Hundreds digit Tens digit Units digit °C
11 EEV B Hundreds digit Tens digit Units digit step
12
The capacity sum of indoor
units
C Tens digit Unit digit
Ɵ˵ʪѣθϑϩΧɇʀʪͱ˙
decimals
kW
13 Protective control D
ߢࡑAͱͱ˝
ߣࡑ²ʪɇϩ˝
Protective control
ߢࡑĘͱťθͱϩʪʀϩЭʪ
control
ߣࡑθʪʪі˝
ߤࡑĘͱࣛϑϩͱΧʒʪ˙θͱϑϩ˝
ߥࡑĮЭʪθࣛͱɇʒ
ߦࡑUϑʀ˵ɇθ˝ʪ
ߧࡑƟͱϩɇʪʪʀϩθʀʀЇθθʪϩ
Frequency status
ߢࡑĘͱθɇ
ߣࡑ²ͱʒ
ߤࡑUͱи
ߥࡑƸΧࢼϩ
ߦࡑUͱиࢼϩ
-
14 IPM temperature E Hundreds digit Tens digit Units digit -
15
The number of connected
indoor units
F Hundreds digit Tens digit Units digit EA
16 View mode end BLANK BLANK BLANK BLANK -
Display contents SEG1 SEG2 SEG3 SEG4
K4
long
push
- Main micom version Year (Dec) Month (Hex) Date (Tens digit) Date (Units digit)
After short
push 1
Inverter micom version Year(Dec) Month (Hex) Date (Tens digit) Date (Units digit)
After short
push 2
E2P version Year(Dec) Month (Hex) Date (Tens digit) Date (Units digit)
After short
push 3
Page 1 - AUTO
Page 2 - (SEG1,2 - Indoor : "A","0") (SEG3,4 - Address : ex)00 )
After short
push 4
Page 1 - MANU
Page 2 - (SEG1,2 - Indoor : "A","0") (SEG3,4 - Address : ex)00 )
• øͱ˝ΧЇϑ˵çߦ࣑đɇʀͱЭʪθ࢏࣒ϑ˵ͱθϩΧЇϑ˵ߣͱθʪ࣑ÃЭ࢏ʀͱЭʪθ࢏࣒ϑ˵ͱθϩΧЇϑ˵ߣͱθʪ࣑kߤť࢏Эʪθ࢏࣒ϑ˵ͱθϩΧЇϑ˵
ߣͱθʪ࣑Їϩͱɇϩʀɇʒʒθʪϑϑ࣒ϑ˵ͱθϩΧЇϑ˵ߣͱθʪ࣑đɇЇɇɇʒʒθʪϑϑ࣒ϑ˵ͱθϩΧЇϑ˵ߣͱθʪ࣑đɇʀͱЭʪθ࢏࣒࢏࢏࢏࢏࢏࢏࢏
Long push K4(View mode end)
