7
English
Installation Procedure
Minimum clearances for the outdoor unit
When installing 1 outdoor unit
(Unit: mm)
150 or more
500 or more
150 or
more
150 or
more
150 or
more
1000
or more
1000
or more
500
or more
150
or more
1000
or more
150 or
more
When installing more than 1 outdoor unit
(Unit: mm)
1000
or more
2000
or more
2000
or more
3000
or more
150
or more
150
or more
150
or more
1500
or more
300
or more
1000 or more
300
or more
150
or more
150
or more
200
or more
300
or more
500 or more 500 or more
300 or more
300 or more
CAUTION
• The outdoor unit must be installed according to the
specified distances in order to permit accessibility
from each side, to guarantee correct operation,
maintenance, and repair of the unit.
The components of the outdoor unit must be
reachable and removable under safe conditions for
people and the unit.
WARNING
• Should adopt bar type louver. Don’t use a type of rain
resistance louver.
[Bar type louver] [Rain resistance louver]
• Louver specifications.
– Angle criteria : less than 20°
– Opening ratio criteria : greater than 80%
To Next Page
