PCB Diagram
116 Samsung Electronics
No. Local Function Description
1 CN302 COMM-OPTION SMW200-05 BLK
2 CN305 COMM INV SMW250-06 WHT
3 CN801 ERROR/COMP CHECK SMW250-04 RED
4 CN12 DC12V YW396-02V BLU
5
CN407
WATER-IN/OUT
SMW250-04 YEL
6 CN001 EVA-IN SMW250-02 WHT
7 CN803 EEV1 SMW250-05 BLU
8 CN407 HIGH PRESSURE SWITCH SMW250-02 BLU
9 CN802 EEV4 SMW250-06 BLU
10 CN306 DOWNLOAD YDW200-20 BLK
11 CN403 OUT TEMP/COND/DISCHARGE/OLP SMW250-10 WHT
12 CN703 BASE HEATER YW396-03AV BLU
13 CN702 4WAY-1 YW396-03AV YEL
14 CN101 POWER YW396-03AV WHT
15 CN806 EEPROM B7P-MQ WHT
16 CN304 DRED DAPC 2009-6P BLK
17 CN501 MODE SELECTOR SMW250-03 WHT
18 CN103 EARTH YDW236-01 WHT
19 CN303 COMM-INDOOR YW396-02V RED
20 CN003 QUIET S/W BR-7623-2P BLK
