PCB Diagram
122 Samsung Electronics
█ SUB-HEATER PCB
(AE080/090/120/160RX****)
No. Local Function Description
1
CN02 POWER YW396-03AV YEL
2 CN03 HEATER YW396-03AV WHT
2
1
This Document can not be used without Samsung’s authorization.
