Reference Sheet
134 Samsung Electronics
Part Description
T_w1 Water Inlet temp sensor
T_w2 Water PHX Outlet temp sensor
T_w3 Water Outlet temp sensor
T_eva in Eva In temp sensor
T_eva out Eva Out temp sensor
T_tank Water tank temp sensor
T_D Discharge temp sensor
PS_H High pressure switch
V_4W 4Way valve
PT_C Charging port
HX_M
Outdoor Heat exchanger
OFM Outdoor fan motor
T_CO Condout temp sensor
HX_PHE Plate heat exchanger
E_M Main expansion valve
7-2 Tank intergrated hydro unit(SPLIT)
