7-3 Tank intergrated hydro unit(MONO)
Part
Description
T_WI Water Inlet temp sensor
T_WO Water PHX Outlet temp sensor
T_w3 Water Outlet temp sensor
T_II Eva In temp sensor
T_tank Water tank temp sensor
T_D Discharge temp sensor
PS_H High pressure switch
V_4W 4Way valve
PT_C Charging port
HX_M Outdoor Heat exchanger
OFM Outdoor fan motor
T_CO Condout temp sensor
HX_PHE Plate heat exchanger
E_M Main expansion valve
