Reference Sheet
136 Samsung Electronics
7-4 Hydro Unit(Split)
Part Description
T_w1 Water Inlet temp sensor
T_w2 Water PHX Outlet temp sensor
T_w3 Water Outlet temp sensor
T_top Compressor Top temp sensor
T_dis Discharge temp sensor
T_eva in Eva In temp sensor
T_eva out Eva Out temp sensor
T_condout Condout temp sensor
PHE Plate heat exchanger
HV Heater vessel
EV
Expansion vessel
