General Overview
Samsung Electronics 19
18 Samsung Electronics
Model Name
Indoor Unit
AE090RNYDEG AE090RNYDEG AE090RNYDEG AE090RNYDGG
Outdoor Unit AE040RXEDEG AE060RXEDEG AE090RXEDEG AE090RXEDGG
Hydro
Unit
Power Supply Φ, #, V, Hz E220~240V, 50Hz, 1Ф E220~240V, 50Hz, 1Ф E220~240V, 50Hz, 1Ф 380~4150V, 50Hz, 3Ф
Water Pump
Type (Model Name) - Centrifurugal (UPM3 25-7.5) Centrifurugal (UPM3 25-7.5) Centrifurugal (UPM3 25-7.5) Centrifurugal (UPM3 25-7.5)
Motor Input W 60 60 60 60
Number of Unit EA 1 1 1 1
Flow Senso
Type (Model Name) - FLOW SENSOR FLOW SENSOR FLOW SENSOR FLOW SENSOR
Min. flow rates LPM 7 7 7 7
Electric Heater W 4,000 4,000 4,000 6,000
Expansion Vessel Liter 8 8 8 8
Pressure Relief Valve bar 2.9 2.9 2.9 2.9
Air Purge Valve Ф, inch BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8"
Service Valve Ф, inch BSPP male 1 1/4" BSPP male 1 1/4" BSPP male 1 1/4" BSPP male 1 1/4"
Sound *3
Sound
Pressure
Heating Std dB(A) 26 26 26 26
Cooling Std dB(A) 26 26 26 26
Sound Power Heating Std dB(A) 40 40 40 40
External
Dimension
Net Weight kg 45.0 45.0 45.0 46.5
Shipping Weight kg 55.0 55.0 55.0 56.0
Net Dimensions (WxHxD) mm 510 x 850 x 315 510 x 850 x 315 510 x 850 x 315 510 x 850 x 315
Shipping Dimensions
(WxHxD)
mm 564 x 1,024 x 426 564 x 1,024 x 426 564 x 1,024 x 426 564 x 1,024 x 426
Outdoor
Unit
Power Supply
Φ, #, V, Hz 220~240V, 50Hz, 1Ф 220~240V, 50Hz, 1Ф 220~240V, 50Hz, 1Ф 380~4150V, 50Hz, 3Ф
Compressor
Type - BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary BLDC Twin Rotary
Model - UB4TN8200FE4SS UB4TN8200FE4SS UB8TN8265FJWSG UB8TN8265FJWSG
Oil Type - POE POE POE POE
Condenser Size - 2RX28S 2RX28S 2RX46S 2RX46S
Motor
Type (Model) - YMAP095AE01A1 YMAP095AE01A1 FMDC531SSA FMDC531SSA
Quantity EA 1 1 1 1
CODE No - DB31-00658D DB31-00658D DB31-00579A DB31-00579A
Fan
Air Flow Rate Cooling CMM 40 43 66 66
Number of Unit EA 1 1 1 1
4-Way Valve Type (Model) - SHF-7H-34U SHF-7H-34U SHF -11H SHF -11H
Base Heater Power Input W N/A N/A 150 150
Sound
Sound
Pressure
Heating Std dB(A) 44 47 49 49
Cooling Std dB(A) 46 47 49 49
Night Mode dB(A) 35 35 35
Sound
Power
Heating Std dB(A) 58 60 64 64
Cooling Std dB(A) 61 62 63 63
External
Dimension
Net Weight kg 46.5 46.5 73.0 72.0
Shipping Weight kg 49.5 49.5 81.5 80.5
Net Dimensions (WxHxD) mm 880 x 638 x 310 880 x 638 x 310 940 x 998 x 330
940 x 998 x 330
Shipping Dimensions
(WxHxD)
mm 1,023 x 742 x413 1,023 x 742 x413 995 x 1,178 x 426 995 x 1,178 x 426
Refrigerant
Type - R32 R32 R32 R32
Control Method - EEV EEV EEV EEV
Factory Charging g 1200 1200 1400 1400
Product Specifications (cont.)
