Disassembly and Reassembly

Samsung Electronics 3-7

No Parts Procedure Remark

6 Ass’y Cover Duct

1) Unscrew two fastening screws on the top of

the Ass’y Cover Duct, lift it up and then pull it

forward to detach.
