Samsung AF24FSSDAWKX - Assy Pcb Main (Control)

PCB Diagram
5-2 Samsung Electronics
ASS'Y PCB MAIN IN (cont.)
①
#1 : DC 310V
#2 : NULL
#3 : AGND
#4 : DC 15V
#5 : CONTROL Signal
#6 : FEED BACK Signal
②
#1 : DC 310V
#2 : NULL
#3 : AGND
#4 : DC 15V
#5 : CONTROL Signal
#6 : FEED BACK Signal
③
#1 : DC 310V
#2 : NULL
#3 : AGND
#4 : DC 15V
#5 : CONTROL Signal
#6 : FEED BACK Signal
④
#1 : DC310V
#2 : NULL
#3 : AGND
#4 : DC15V
⑤
#1 : FUSE Signal
#2 : GND
⑥
#1 : DC 12V
#2 : GND
#3 : CURRENT1
#4 : CURRENT2
#5 : RADICAL1
#6 : RADICAL2
#7 : RADICAL3
#8 : RADICAL4
#9 : PUMP
#10 : WATER LEVEL
#11 : VOL_LEVEL
#12 : DC 5V
⑦
#1 : F1
#2 : NULL
#3 : F2
⑧
#1 : DC 12V
#2 : MOTOR Operation signal
#3 : MOTOR Operation signal
#4 : MOTOR Operation signal
#5 : MOTOR Operation signal
#6 : DC 12V
#7 : MOTOR Operation signal
#8 : MOTOR Operation signal
#9 : MOTOR Operation signal
#10 : MOTOR Operation signal
⑨
#1 : DC 12V
#2 : GND
#3 : DC 5V
#4 : NULL
#5 : NULL
#6 : BLDC PS
#7 : NULL
#8 : NULL
⑩
#1 : DC 12V
#2 : GND
#3 : PANEL Transmission
signal
#4 : PANEL Reception signal
#5 : NULL
#6 : DC 5V
⑪
#1 : DC 12V
#2 : MOTOR Operation signal
#3 : MOTOR Operation signal
#4 : MOTOR Operation signal
#5 : MOTOROperation signal
⑫
#1 : SPI Control signal 1
#2 : SPI Control signal 2
#3 : DC 12V
#4 : NULL
⑬
#1 : GND
#2 : K1 MODE
#3 : K1 FEEDBACK
#4 : DC 12V
⑭
#1 : Temperature sensing signal
#2 : GND
#3 :Temperature sensing signal
#4 : GND
⑮
#1 : Temperature sensing signal
#2 : NULL
#3 : GND
⑯
#1: RXD_485
#2: TXD_485
#3: nTRST
#4: TDO
#5: TCK
#6: TDI
#7: TMS
#8: TRACE_CLK
#9: GND
#10: VCC
#11: VCC
#12: MD0
#13: RESET
#14: TRACE_3
#15: F_SCLK
#16: F_SDAT
#17: GND
#18: TRACE_2
#19: TRACE_1
#20: TRACE_0
CN200 - BLDC Motor(Top) 2:CN201 - BLDC Motor(Middle)
3:CN202 - BLDC
Motor(Bottom)
4:CN270 – BLDC Power
5:CN32 - Terminal
Block Fuse
8:CN23 – Blade Motor
CN21 - Blade Motor(Spare)
CN100 - Downloading
CN700 - Virus Doctor
13:CN60 – Zero Filter
CN31 – Indoor Pipe sensor CN30 – Indoor Room Sensor
6:CN600 - Sterilization
washing
7:CN500 - Indoor/
Outdoor COMM
9:CN41 - POWER PBA
Connection
10:CN40 - POWER
PBA Connection
