Disassembly and Reassembly

3-26 Samsung Electronics

No Parts Procedure Remark

6 Ass'y

Cabinet Front LF

1) Unscrew the 11 fastening screws of the Ass'y

Cabinet Front LF . (Use +Screw Driver)
