Disassembly and Reassembly
Samsung Electronics 3-57
No Parts Procedure Remark
2) Disassemble Sensor on the Evap.
3) Disassemble 2 indicating screws which are in
the near of Hanger Plate to detach the Evap.
(1 screw each at left and right side)
It needs 2 peoples.

Samsung AM160FNBFGB/EU Specifications

General

Model	AM160FNBFGB/EU
Type	Heat Pump
Cooling Capacity	16.0 kW
Heating Capacity	18.0 kW
Energy Efficiency Class (Cooling)	A++
Energy Efficiency Class (Heating)	A+
Refrigerant	R410A
Operating Temperature Range (Heating)	-20°C to 24°C
Power Supply	50Hz
Dimensions (Outdoor Unit)	940 x 330 mm
