Samsung AR12TVFCAWKXAP - Page 22

22
NO. Parts Procedure Remark
1 PANEL-FRONT 9)Raise the PANEL FRONT upward
asshownintheguretoseparate
the 3 hooks.
2 CONTROL-IN 10)To open the CONTROL-IN,
raisethesideangesofthe
PLATE-RIGHT at an angle and un-
lock 2 hooks.
11)To detach the CONTROLIN,
unfasten a screw back of the
PLATE-LEFTasshowningures.
(use (+) Screw Driver)
