9-1 Name of Each Part
9-1-1 Indoor Unit
The design and shape are subject to change according to the model.
- Main Parts
01
02
03
04
09
05
06
08
07
01 Air intake
02 Airlter
03 Tri-carelter(ForAR**T*EA***models)
04 Wind-Free panel
05Airowblade (up and down)
06Airowblade(leftandright
07 Power button/Remote control receiver
08 Room temperature sensor
09 Display
