6-3 ASSY PCB DISPLAY CODE DB92-04833C
Parts Code Design Loc Parts Description Spec. Quantity Unit
0201-001528 COATING ADHESIVE-SIL LDC2577D,Y/GRN,175CPS 0.9 G
DB61-07412A CASE-LED CASE-LED AR9500T, QMD RAC,HIPS,T1.8,L69,BLACK,8.8 1 PC
DB64-03476A
WINDOW DIS-
PLAY
WINDOW DISPLAY AR9500T, QMD RAC,PET,T0.27,8.8 FILM, AI, Timer, Wi-Fi 1 PC
DB94-08165A ASSY PCB SMD DISPLAY_DLX,QMD RAC AR9500T,84.5x50mm,EXTERNAL WIFI,DB92-04833C 1 PC
0202-001933 SOLDER-CREAM SOLDER-CREAM LFM-48W TM-HP,D20~38um,96.5Sn/3Ag/0.5Cu,Flux 12% 1.2 G
0404-001250 D100 DIODE-SCHOTTKY RB520G-30,30V,100mA,VMD2,TP 1 PC
0406-001005 TD2 DIODE-TVS SM05,6V,20MAV,TP 1 PC
0406-001084 TD1 DIODE-TVS SMF05,6/-/-V,200W,SC70-5L 1 PC
0406-001594 TD3 DIODE-TVS P6SMB24CAT3G,22.8/24/25.2V,600W,SMB 1 PC
0601-001986 A-1 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 A-2 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 A-3 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 A-4 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 A-5 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 A-6 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 A-7 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 B-1 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 B-2 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 B-3 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 B-4 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 B-5 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 B-6 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 B-7 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 DOT-1 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 HUM-1 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 INDI-2 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 INDI-3 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 INDI-4 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 KWH-1 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0601-001986 TEMP-1 LED
SMD(Top View),WHT,WATER CLEAR,1.6x0.8mm,1.6x0.8x0.4mm,1,120deg,70/90
mcd,-40to+85C,-,75mW,-,-,TP,INDICATOR
1 PC
0609-001484 REM1 MODULE REMOCON HORIZONTAL-SMD(TOP),6.0mm,TR,0,38KHz,2.3mm 1 PC
1003-002963 IC1 IC-LED DRIVER ADT8700A,LQFP,32P,7x7mm,500mA,TR,PLASTIC,5-15V,-40to+85C,1.12W,5V 1 PC
2007-001121 R20 R-CHIP 680ohm,5%,1/4W,TP,3216 1 PC
2007-001121 R21 R-CHIP 680ohm,5%,1/4W,TP,3216 1 PC
