24
NO. Parts Procedure Remark
2
CONTORL IN 15)Unfasten a screw of the Ground
wire and pick up Temperature
wires from ASSY EVAP.
(Use (+) Screw Driver.)
16)TheCONTROL-INisxedto
HOLER PIPE by a hook bottom
of the case as shown in the last
gure.
(Please loosen remaining
connectors before detaching
CASECONTROL.
Caution:
When you separate the connector,
pull pressing the locking button
17) Put down of the HOLDER PIPE
and push up the hook and lean
sidethecaseasshowningures.
To Next Page
