Samsung AR12TVFCAWKXAP - Page 31

31
NO. Parts Procedure Remark
2 Fan
&
Motor
1) Detach the Nut Flange like the
picture on the right side.
(Turn clockwise because the
screw is left-handed.)
(Use Monkey Spanner.)
2) Detach the Fan Propeller.
3)Loosen4xingscrewstodetach
the Motor.
(Use Monkey Spanner.)
4) Disconnect the wire between
Ass’y Control Out and Motor.
5)Loosenxingboltsand
detach the Bracket Motor
