34
4-4. Outdoor Unit (Q-480)
AR18TVEAAWKXAP AR18TVFCBWKXAP
AR24TVEAAWKXAP AR24TVFCAWKXAP
NO. Parts Procedure Remark
1 COMMON
WORK
1)Loosenxingscrewsfromthe
cabi side Rh and detach it.
2) L oosen each sc rews and detach
the Cabi Top Cover.
3)Loosenxingscrewsfromthe
cabi side.
4)Loosenxingscrewsfromthe
cabi side Rh and detach it.
