2-2 Product specication
Model AR12TVFCAWK/AP AR18TVFCBWK/AP AR24TVFCAWK/AP
Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted
Capacity
T1 Cool W 11500 18000 21000
T3 Cool W - - -
Heat W - - -
Power Input
T1 Cool W 1020 1460 1900
T3 Cool W - - -
Heat W - - -
Current
T1 Cool A 4.8 6.8 8.7
T3 Cool A - - -
Heat - - - -
Efciency
EER W/W (3.3) 12.33 (3.61) 11.05 (3.24)
- - -
COP W/W - - -
Dehumidifying l/hr. 2 2.5
Platform
IDU - QF1 QF3 QF3
ODU - N-WW Q-480 Q-480
Evap
Main -
Φ7,2R*9(10)S*591mm,
H1.3, N.G.S, 1by2
Φ7,2R*10S*825.5mm,H1.3,
N.G.S, 4by4
Φ7,2R*10S*825.5mm,H1.3,
N.G.S, 4by4
Sub -
Φ7,2R*5(6)S*591mm,H1.3,
N.G.S : (Q-1-5)
Φ7,2R*5(6)S*826mm,H1.3,
N.G.S : (Q-3-3)
Φ7,2R*5(6)S*825.5mm,
H1.3, N.G.S : (Q-3-3)
Cond
Main -
Φ7,2R*24S*706mm,Lou-
ver1.4, N.G.S, 3by3by1
Φ7,2R*28S*915mm,Lou-
ver1.4, N.G.S, 4by4by1
Φ7,2R*28S*915mm,Lou-
ver1.4, N.G.S, 4by4by1
Sub - - - -
Comp
Model - UB1AR1090FE6 UG9TK3150FE4 UG9TK3150FE4
OLP - - - -
Motor In
Code - DB31-00694A DB31-00636A DB31-00636A
Name - - - -
Motor Out
Code - DB31-00693A DB31-00642C DB31-00642C
Name - - - -
Expansion Φ*L - EEVΦ1.4 EEVΦ1.65 EEVΦ1.65
Refrigerant
type - R410A R410A R410A
charge g 1000 g 1400 g 1400 g
SVC Valve
Liquid /
Gas
- 6.35/9.52 6.35/12.7 6.35/15.88
Tube Dis. / Suc. - 7.94/9.52 9.52/12.7 9.52/12.7
Drain hose D*L mm 20*550 20*550 20*550
4-WAY V/V - - - -
Power Supply V/Hz/Φ 220/(50/60)/1 220/(50/60)/1 220/(50/60)/1
Climate Class - T1 T1 T1
Noise
IDU UT,T dB 43 47 48
ODU dB 53 57 59
Net Size
(W*H*D)
IDU
mm
820*299*215 1055*299*215 1055*299*215
ODU 720*548*265 880*638*310 880*638*310
Weight
IDU
kg
8.9 11.5 11.5
ODU 25.4 38.1 38.1
Operation
range
Cooling
IDU 16℃~32℃ 16℃~32℃ 16℃~32℃
ODU 16℃~46℃ 16℃~46℃ 16℃~46℃
Heating IDU - - -
ODU - - -
