....4 D401 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
....4 D402 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T
....4 D403 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D404 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
....4 D405 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L
....4 D406 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D407 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D408 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L
....4 D411 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 D413 0402-000537 DIODE-RECTIFIER;RH1A,600V,0.6A,DO-204AC
....4 D501 2004-000433 R-METAL;1Kohm,1%,1/8W,AA,TP,1.8x3.2mm
....4 D502 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D601 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D602 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D801 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20
....4 D803 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 D804 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D810 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D811 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D816 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 D901 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D902 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D903 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D904 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D905 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D906 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D907 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D909 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ202 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ203 0403-001321 DIODE-ZENER;MTZJ6.8C,6.66-7.01V,500mW,DO
....4 DZ302 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
....4 DZ303 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
....4 DZ304 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
....4 DZ305 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D
....4 DZ306 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
....4 DZ401 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
....4 DZ402 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 DZ502 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
....4 DZ503 2004-000500 R-METAL;2.7Kohm,1%,1/8W,AA,TP,1.8x3.2m
....4 DZ504 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
....4 DZ601 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
....4 DZ603 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ801 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO
....4 DZ802 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ803 0403-001167 DIODE-ZENER;MTZJ30D,30V,29.02-30.51V,500
....4 DZ804 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
....4 DZ805 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL
....4 DZ806 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ808 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO
....4 DZ901 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ904 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ905 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ906 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ907 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm
....4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm
....4 FA802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS
....4 FA803S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M
....4 HIC202 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP
....4 HIC203 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP
....4 HIC204 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP
....4 IC903 1203-001944 IC-POSI.FIXED REG.;78RM33,TO-220,3P,-,PL
....4 IC904 1203-001943 IC-VOL. DETECTOR;7025,TO-92,3P,-,PLASTIC
....4 J706 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 J718 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 J901 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 J904 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 L102 2701-000159 INDUCTOR-AXIAL;22uH,10%,4.2x9.8mm
....4 L103 2701-000115 INDUCTOR-AXIAL;10uH,10%,3x7mm
....4 L201 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L202 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
....4 L207 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L208 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L209 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L210 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L212 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L301 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L302 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L303 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L401 2001-001053 R-CARBON(S);1.5OHM,5%,1/2W,AA,TP,2.4X6.4
....4 L406 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L407 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L410 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L412 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L501 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L601 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L604 2701-000169 INDUCTOR-AXIAL;3.9uH,10%,2.5x3.4mm
....4 L605 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L606 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L607 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L608 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L609 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L701 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L702 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L705 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L706 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L709 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L710 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L711 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L801 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
....4 L802 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L803 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L804 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L806 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
....4 L807 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L809 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L901 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
....4 L903 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
....4 L904 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
....4 L905 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 L907 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L908 2701-000191 INDUCTOR-AXIAL;47uH,10%,2.5x3.4mm
....4 L909 2701-000191 INDUCTOR-AXIAL;47uH,10%,2.5x3.4mm
....4 PCB AA41-00168C PCB-MAIN;KS3A,FR-1,1L,C,1.6T,330x245,-, S.N.A
....4 Q201 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6
....4 Q404 0505-000156 FET-SILICON;IRF620,N,200V,5A,0.8ohm,50W,
....4 Q501 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
....4 Q601 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q701 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q901 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q902 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q903 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q904 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q905 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q906 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q908 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q909 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m
....4 Q910 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m
....4 R102 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R103 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R105 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R106 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R202 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R203 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R204 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R205 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R206 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R207 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R208 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R209 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R210 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R212 2004-000218 R-METAL;10Kohm,1%,1/8W,AA,TP,1.8x3.2mm
....4 R213 2001-000232 R-CARBON;1.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
Electrical Parts List
