Electrical Parts List
Samsung Electronics 7-1
ASSY PCB MAIN(OPT)
1 * AA94-02759K ASSY PCB MAIN(OPT);CS29A5HT8X/BWT,KS3A,R
..2 BOT1 AA39-00046E LEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,JU
..2 C-BLOC AA26-00069A TRANS FBT;FUJ-29C002C(S),DREAM3,4,-,-,-,
..2 C423 2301-001296 C-FILM,MPPF;720NF,5%,400V,BK,26X15.5X20M
..2 C820 2401-003076 C-AL;3300uF,20%,50V,WP,BK,18x35.5mm
..2 CLAMP AA65-30109A CLAMP-FBT;NYLON-66,V2,BLK,-,-,- S.N.A
..2 CLAMP AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 CLAMP AA65-30105C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,5MM S.N.A
..2 CLAMP AA65-30104C CLAMP-WIRE;NYLON 66,V2,NTR,W1 Z4,ALL MOD S.N.A
..2 CLAMP AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 D-COIL AA27-00128A COIL DEGAUSSING;-,-,-,-,50T,7,-,29inch,2
..2 D211 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
..2 D801S AA96-00276A ASSY H/S;-,BRIDGE,AA62-00052A,RBV606,WA
...3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
...3 AA62-00052A HEAT SINK-PS;-,-,-,SILVER,HOLE 18.5mm, 2 S.N.A
...3 AA60-30003A WASHER;-,-,-,T1.5,-,SBHG-1,- S.N.A
...3 0402-000549 DIODE-BRIDGE;RBV606,600V,6A,-,BK
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 HC401 AA96-00291B ASSY H/S;-,POWER,AA62-00051B,2SC5446 +
...3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
...3 AA62-30177A HEAT-SINK,PN;-,CUS-1,T1.0,-,KCV12D,-,-,1 S.N.A
...3 AA62-00051B HEAT SINK-PS;-,-,-,SILVER,HOLE 34mm,ALL, S.N.A
...3 AA60-30001A WASHER-PLATE;M3,ID3.5,15X8.5,T1.0,-,SBHG S.N.A
...3 AA02-00007A MICA;DPM-04,MICA,22x29x0.15mm
...3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
...3 0502-001175 TR-POWER;2SC5446,NPN,200000mW,TO-3PL,BK
...3 0402-001296 DIODE-RECTIFIER;FMP-3FU,1.5KV,5A,TO-3PF,
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 HC801 AA96-00475A ASSY H/S;-,REGULATOR,AA62-00066B,FML-G1
...3 AA62-00066B HEAT SINK;D2,D3,AL ,T1.0,89,70,-,AA62-00 S.N.A
...3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
...3 1203-001006 IC-VOLTAGE REGULATOR;78R05,TO-220F,4P,-,
...3 0402-001230 DIODE-RECTIFIER;FMG-G2CS,1000V,3A,TO-220
...3 0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,-
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 HIC401 AA13-00094A IC HYBRID;-,DDRI001A,SIP,5P,-,TP
..2 IC201S 1204-001727 IC-VIDEO PROCESS;VDP3140D-E5,DIP,64P,-,P
..2 IC301 AA96-50381A ASSY-H/S;-,-,AA62-30180B,LA7845,-
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 1204-000517 IC-VERTIVAL DEF.;LA7845,SIP,7P,-,PLASTIC
...3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
...3 AA62-30180B HEAT SINK-ES;-,A6063 EXTR.,2,WHT,70MM,-, S.N.A
..2 IC602 AA96-50369B ASSY-H/S;-,-,AA62-30181F,TDA7297,-
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 1201-001064 IC-POWER AMP;7297,ZIP,15P,-,DUAL,32DB,PL
...3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
...3 AA62-30181F HEAT SINK-ES;-,AL6063 EXTR.,2,WHT,50MM,- S.N.A
..2 IC801S AA96-50371C ASSY-H/S;-,-,AA62-30181H,KA3S1265R,-
...3 AA62-30181H HEAT SINK-ES;-,AL6063 EXTR.,2,WHT,50MM,- S.N.A
...3 AA61-10386A BRACKET-IC;-,-,SECC 100,T1.0,-,KA2S0680, S.N.A
...3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
...3 1203-001482 IC-PWM CONTROLLER;3S1265R,TO-3P,5P,210,P
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 IC804 AA96-00243C ASSY H/S;-,REGULATOR,AA62-00045A,KA7806
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 1203-000284 IC-POSI.FIXED REG.;7806,TO-220,3P,-,PLAS
...3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
...3 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, S.N.A
..2 IC901 AA09-00041A IC-MCU;SDA555X-OTP,SDA555X-OTP,-,-,52
..2 JA701 3722-000195 JACK-SCART;42P,-,SN,BLK,NO
..2 L402 AA27-10004F COIL-CHOKE;-,56uH,K,-,2.5A,BK,-,DR12x15,
..2 L403 AA27-00015A COIL-LINEARLITY;-,7.3UH,L81 DR15X18,-,-,
..2 L408 AA27-00031A COIL-HORIZ.WIDTH;-,140UH,AR 8X20,0.8MM,B
..2 Q402 0505-001116 FET-SILICON;BUZ73A,N,200V,22A,0.6ohm,40W
..2 Q404 AA96-00437A ASSY H/S;-,MAIN,AA62-00076A,IRF620,100H
...3 0505-000156 FET-SILICON;IRF620,N,200V,5A,0.8ohm,50W,
...3 AA62-00076A HEAT SINK;100Hz,AL ,T1.0,10,40,-,-,- S.N.A
...3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
..2 S-H/S AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 T444S AA26-00082A TRANS FBT;FUJ-29C002F(S),CT29A7DR,1.95mH
..2 T801S AA26-00046A TRANS SWITCHING;-,-,-,AC90~260V,DC135/16
..2 TUBE AA39-00108A LEAD CONNECTOR-ASSY;,-,-,-,-,-,-,GRT-TUB
..2 Z AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA39-20010C LEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,600
..2 AA95-00871A ASSY-PCB,VIDEO S/W;-,100HZ,KS3A,PAL,-,-
...3 CNS01 3711-002704 CONNECTOR-HEADER;NOWALL,6P,1R,2.5mm,ANGL
...3 CNS02 3711-002706 CONNECTOR-HEADER;NOWALL,8P,1R,2.5mm,ANGL
...3 ICS01 1001-001114 IC-VIDEO SWITCH;TEA6425,VIDEO SWITCH ,DI
...3 PCB AA41-00153E PCB-VIDEO SWITCH;CS29A6,FR-1,1L,E,1.6T,2 S.N.A
...3 AA99-20082H ASSY-PCB SUB,AUTO; AA95-00871A ,V S.N.A
....4 CS01 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 CS02 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 CS03 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 CS04 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 CS05 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 CS06 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 CS07 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
....4 CS08 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 DZS01 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZS02 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 LS01 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 QS01 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 QS02 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 QS03 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 RS01 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RS02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RS03 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RS04 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RS05 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RS06 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RS07 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RS10 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RS11 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RS12 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RS13 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
..2 AA61-00462B SUPPORT-HEAT SINK;21A9,ABS,GRAY,VO,-,-,- S.N.A
..2 AA99-30192G ASSY-PCB ROBOT; AA94-02759K ,ER S.N.A
...3 C405 2303-001015 C-FILM,PPF;5.5nF,5%,1.6kV,TP,29x9.5x17,2
...3 C406 2303-001015 C-FILM,PPF;5.5nF,5%,1.6kV,TP,29x9.5x17,2
...3 C407 2301-001338 C-FILM,MPE-PPF;0.68nF,5%,1.6kV,TP,28x7x1
...3 C426 2306-000195 C-FILM,MPPF;360nF,5%,400V,TP,26x19x11.5,
...3 C803 2401-003576 C-AL;470uF,20%,450V,GP,ST,35x45mm,1
...3 C815 2401-003026 C-AL;330uF,20%,200V,GP,ST,22x35,10
...3 CN501 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
...3 CN902 3711-003043 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH
...3 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
...3 CX802S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
...3 CY802S 2201-002002 C-CERAMIC,DISC;4.7nF,20%,400V,Y5U,TP,16x
...3 FP801S 3601-000297 FUSE-CARTRIDGE;250V,5A,TIME-LAG,GLASS,5.
...3 IC202 1203-001944 IC-POSI.FIXED REG.;78RM33,TO-220,3P,-,PL
...3 IC401 1202-000103 IC-VOLTAGE COMP.;393,DIP,8P,300MIL,DUAL,
...3 IC601 1204-001661 IC-SOUND PROCESSOR;MSP3411G-A2,DIP,52P,-
...3 IC803 1203-001697 IC-VOLTAGE REGULATOR;78R08,TO-220,4P,-,P
...3 IC902 1103-001171 IC-EEPROM;L51DC,16KBit,DIP,8P,300MIL,10m
...3 L405 AA27-00096A COIL HORIZ. WIDTH;-,10.0mH,DR15 X 27.5,U
...3 L808 AA27-00098A COIL CHOKE;-,-,24uH,10%,-,0.1,3.0A,DR10X
...3 LX801S AA29-30002N FILTER-LINE NOISE;-,16MH,1.5A,AC100~260V
...3 LX802S AA29-30002N FILTER-LINE NOISE;-,16MH,1.5A,AC100~260V
...3 NT802S 1404-001045 THERMISTOR-NTC;4.7OHM,15%,2900K,35.0MW,T
...3 PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST
...3 PT801S 1404-000002 THERMISTOR-PTC;9ohm,20%,-,-,TR,RECT,-
7-1 CS29A5HT8X/BWT
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
7. Electrical Parts List
To Next Page
