...3 RL801S 3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS,
...3 T401 AA26-50001S TRANS-HORIZ.DRIVE;-,6.0mH,44uH,1.5uH,EI2
...3 TU01S AA40-00060A TUNER-F/S;TCPS3001PD09D(S),-,PAL-M(NTSC)
...3 AA99-10187U ASSY-PCB MAIN,AUTO; AA99-30192G ,V S.N.A
....4 C103 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
....4 C104 2401-003578 C-AL;1000uF,20%,10V,GP,TP,8x20mm,5
....4 C105 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
....4 C106 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5
....4 C113 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V
....4 C115 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C116 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C201 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
....4 C202 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C205 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C206 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C207 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C208 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
....4 C209 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
....4 C211 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
....4 C212 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C213 2301-000247 C-FILM,PEF;33nF,5%,50V,TP,8.1x4.5x13mm,5
....4 C214 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C215 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C216 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C217 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
....4 C218 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C219 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C220 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C221 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C222 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C223 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C224 2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
....4 C225 2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
....4 C228 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
....4 C229 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
....4 C230 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
....4 C231 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C232 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C233 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C234 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C235 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C236 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C237 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
....4 C239 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C240 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C242 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
....4 C244 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C245 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C246 2202-000210 C-CERAMIC,MLC-AXIAL;270PF,10%,50V,Y5P,TP
....4 C247 2202-000849 C-CERAMIC,MLC-AXIAL;18pF,5%,50V,CH,TP,3.
....4 C248 2202-000210 C-CERAMIC,MLC-AXIAL;270PF,10%,50V,Y5P,TP
....4 C249 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C250 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C302 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
....4 C303 2201-002103 C-CERAMIC,DISC;0.015nF,5%,500V,NP0,TP,6.
....4 C304 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15
....4 C305 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
....4 C306 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,
....4 C307 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
....4 C308 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C401 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
....4 C402 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
....4 C403 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
....4 C404 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
....4 C408 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm
....4 C409 2301-001268 C-FILM,PPF;33nF,5%,630V,TP,20x11x17,7.5
....4 C411 2301-000232 C-FILM,PEF;3.3nF,5%,50V,TP,8.1x4.5x13mm,
....4 C412 2301-000148 C-FILM,PEF;10nF,5%,100V,TP,7x3.2x7mm,5mm
....4 C413 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
....4 C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
....4 C415 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,
....4 C416 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
....4 C418 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
....4 C421 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
....4 C422 2401-001527 C-AL;47uF,20%,250V,HR,TP,13x25mm,5m
....4 C424 2201-000132 C-CERAMIC,DISC;0.1nF,10%,500V,Y5P,TP,6.5
....4 C425 2301-001259 C-FILM,MPPF;100nF,5%,400V,TP,19x8x16,7.5
....4 C601 2201-000558 C-CERAMIC,DISC;0.47nF,10%,50V,Y5P,TP,5x3
....4 C603 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C604 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
....4 C605 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C607 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
....4 C608 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
....4 C610 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
....4 C611 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
....4 C612 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
....4 C613 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
....4 C617 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
....4 C620 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C621 2401-002458 C-AL;1000uF,20%,35V,GP,TP,16x25,7.5
....4 C622 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
....4 C623 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C624 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C625 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
....4 C626 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
....4 C627 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C628 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
....4 C629 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C630 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C631 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C632 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
....4 C634 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C635 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C636 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
....4 C637 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
....4 C638 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C639 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C640 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
....4 C641 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
....4 C642 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C643 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
....4 C644 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C645 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C646 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C647 2202-000286 C-CERAMIC,MLC-AXIAL;56pF,5%,50V,SL,TP,1.
....4 C649 2301-000108 C-FILM,PEF;1.5nF,5%,50V,TP,6.5x3.0x5.5mm
....4 C652 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C654 2201-000611 C-CERAMIC,DISC;0.056nF,5%,50V,NP0,TP,7x3
....4 C656 2201-000304 C-CERAMIC,DISC;0.001nF,0.25pF,50V,NP0,TP
....4 C657 2201-000304 C-CERAMIC,DISC;0.001nF,0.25pF,50V,NP0,TP
....4 C701 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C702 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
....4 C707 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
....4 C708 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C804 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250V,Y5U,TP,9x4
....4 C805 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250V,Y5U,TP,9x4
....4 C807 2301-001397 C-FILM,PPF;2.2nF,5%,1.2kV,TP,15x8.5x13.5
....4 C808 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
....4 C809 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
....4 C810 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
....4 C811 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
....4 C814 2201-000406 C-CERAMIC,DISC;0.27nF,10%,2kV,Y5P,TP,6.3
....4 C816 2401-000293 C-AL;100uF,+30-10%,200V,GP,TP,16x25
....4 C817 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
....4 C818 2401-000722 C-AL;2200uF,20%,25V,WT,TP,16x25,7.5
....4 C819 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
....4 C821 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
....4 C822 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
....4 C823 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
....4 C824 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
....4 C825 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C826 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5
....4 C827 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5
....4 C829 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C831 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C832 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C833 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
....4 C835 2401-002289 C-AL;470uF,20%,35V,WT,TP,10x20,5
....4 C837 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C838 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C839 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
Electrical Parts List
7-2 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
To Next Page
