Electrical Parts List
Samsung Electronics 7-3
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
....4 C840 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5
....4 C841 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5
....4 C901 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C902 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
....4 C903 2202-000719 C-CERAMIC,MLC-AXIAL;6.8NF,20%,16V,Y5R,3.
....4 C905 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
....4 C907 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C908 2202-000863 C-CERAMIC,MLC-AXIAL;560pF,10%,50V,Y5P,TP
....4 C909 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
....4 C910 2201-000980 C-CERAMIC,DISC;0.03nF,5%,50V,NP0,TP,5x3,
....4 C911 2201-000980 C-CERAMIC,DISC;0.03nF,5%,50V,NP0,TP,5x3,
....4 C912 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
....4 C913 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C914 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C915 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C916 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C917 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
....4 C918 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 C919 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C920 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C921 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C922 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C923 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
....4 C924 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 CN502 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
....4 CN602 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH
....4 CN702 3711-002647 CONNECTOR-HEADER;BOX,8P,1R,2.5mm,STRAIGH
....4 CN704 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
....4 CN901 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH
....4 CW901 2503-000156 C-NETWORK;100pFx4,20%,50V
....4 D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D202 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D203 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D204 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D205 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D206 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D207 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D208 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D209 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D210 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D301 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 D401 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
....4 D402 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T
....4 D404 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T
....4 D405 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D406 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D408 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D411 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T
....4 D602 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D604 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D801 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20
....4 D803 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 D804 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D808 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D810 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D811 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D816 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 D901 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D902 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D903 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D904 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
....4 D906 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 D907 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ202 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ203 0403-001321 DIODE-ZENER;MTZJ6.8C,6.66-7.01V,500mW,DO
....4 DZ204 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ205 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ206 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ302 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
....4 DZ303 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
....4 DZ304 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
....4 DZ305 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D
....4 DZ306 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
....4 DZ401 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
....4 DZ402 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 DZ601 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
....4 DZ603 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ605 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ801 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO
....4 DZ802 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ803 0403-001167 DIODE-ZENER;MTZJ30D,30V,29.02-30.51V,500
....4 DZ804 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
....4 DZ805 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL
....4 DZ806 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ808 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO
....4 DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ904 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ905 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ906 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ907 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ908 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ909 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 DZ910 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
....4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm
....4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm
....4 FA802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS
....4 FA803S 3601-001228 FUSE-AXIAL LEAD;125V,10A,FAST-ACTING,EPO
....4 HIC201 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP
....4 HIC202 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP
....4 HIC203 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP
....4 HIC204 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP
....4 IC903 1203-001944 IC-POSI.FIXED REG.;78RM33,TO-220,3P,-,PL
....4 IC904 1203-001943 IC-VOL. DETECTOR;7025,TO-92,3P,-,PLASTIC
....4 J231 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 J401 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 J412 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
....4 J901 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 J904 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 L102 2701-000200 INDUCTOR-AXIAL;5.6uH,10%,4.2x9.8mm
....4 L103 2701-000115 INDUCTOR-AXIAL;10uH,10%,3x7mm
....4 L108 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L109 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L201 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L202 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
....4 L207 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L208 2701-000146 INDUCTOR-AXIAL;2.2uH,10%,2.5x3.4mm
....4 L209 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L210 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L212 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L301 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L302 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L303 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L401 2001-001038 R-CARBON(S);0.56OHM,5%,1/2W,AA,TP,2.4X6.
....4 L406 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L407 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L410 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
....4 L601 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L604 2701-000169 INDUCTOR-AXIAL;3.9uH,10%,2.5x3.4mm
....4 L605 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L606 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L607 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L608 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L609 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L701 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L702 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L705 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L706 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
....4 L709 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L710 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
....4 L711 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L801 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
....4 L802 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L803 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L804 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L806 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
....4 L807 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L809 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 L901 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
....4 L902 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
....4 L903 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
