....4 L904 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
....4 L905 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 L907 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
....4 L908 2701-000191 INDUCTOR-AXIAL;47uH,10%,2.5x3.4mm
....4 L909 2701-000191 INDUCTOR-AXIAL;47uH,10%,2.5x3.4mm
....4 PCB AA41-00168F PCB-MAIN;CS29A6,FR-1,1L,F,1.6T,330x245, S.N.A
....4 Q201 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q601 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q701 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q802 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO-
....4 Q901 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q902 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q903 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q906 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q908 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 Q909 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m
....4 Q910 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m
....4 R102 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R103 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R105 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R106 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R202 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R203 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R204 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R205 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R206 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R207 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R208 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R209 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R210 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R211 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R212 2004-000218 R-METAL;10Kohm,1%,1/8W,AA,TP,1.8x3.2mm
....4 R214 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R215 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R216 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R224 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R225 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R226 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R228 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R231 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R232 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R233 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 R235 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R236 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R237 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R238 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R241 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R242 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R243 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R244 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R245 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R246 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R247 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R248 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R249 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R250 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R252 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R253 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R254 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R301 2001-001054 R-CARBON(S);1.6KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R302 2004-001403 R-METAL(S);7.5Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 R303 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM
....4 R304 2003-002228 R-METAL OXIDE(S);0.47ohm,5%,2W,AG,TP,3.9
....4 R305 2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM
....4 R306 2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM
....4 R309 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R310 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R313 2004-001137 R-METAL;6.8Kohm,1%,1/8W,AA,TP,1.8x3.2m
....4 R314 2004-001893 R-METAL(S);22Kohm,1%,1/2W,AA,TP,2.5x6.5m
....4 R401 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12
....4 R402 2003-000586 R-METAL OXIDE(S);22Kohm,5%,2W,AF,TP,4x12
....4 R404 2001-001038 R-CARBON(S);0.56OHM,5%,1/2W,AA,TP,2.4X6.
....4 R405 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10
....4 R407 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R409 2003-001018 R-METAL OXIDE(S);220ohm,5%,2W,AF,TP,3.9x
....4 R410 2003-001018 R-METAL OXIDE(S);220ohm,5%,2W,AF,TP,3.9x
....4 R411 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R413 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10
....4 R414 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m
....4 R415 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R417 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 R418 2001-001159 R-CARBON(S);510OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R420 2004-004015 R-METAL(S);9.1Kohm,1%,1/2W,AA,TP,2.5x6.5
....4 R421 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R422 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R423 2004-004048 R-METAL(S);3.9Kohm,1%,1/2W,AA,TP,2.5x6.5
....4 R424 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10
....4 R425 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10
....4 R426 2003-000540 R-METAL OXIDE(S);1Kohm,5%,2W,AF,TP,4x12m
....4 R433 2003-001042 R-METAL OXIDE(S);5.6Kohm,5%,2W,AF,TP,3.9
....4 R434 2003-002064 R-METAL OXIDE;7.5ohm,5%,2W,AF,TP,10x3.9m
....4 R601 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R602 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R603 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R604 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R605 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R606 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R607 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R608 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R609 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R612 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R613 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R614 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R615 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R616 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R617 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R621 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R622 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R627 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R628 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R629 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R702 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R703 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R704 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R705 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R706 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R707 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R708 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R709 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R710 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R711 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R712 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R715 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R716 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R717 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R718 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R719 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R723 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R724 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R725 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R726 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R802 2003-001025 R-METAL OXIDE(S);15Kohm,5%,2W,AF,TP,3.9x
....4 R803 2003-001025 R-METAL OXIDE(S);15Kohm,5%,2W,AF,TP,3.9x
....4 R804 2003-001025 R-METAL OXIDE(S);15Kohm,5%,2W,AF,TP,3.9x
....4 R805 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R806 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R807 2006-001083 R-CEMENT;120ohm,5%,5W,CJ,TP,14x10x27mm
....4 R808 2001-001079 R-CARBON(S);15OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R809 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R810 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R811 2004-001408 R-METAL(S);91Kohm,1%,1/2W,AA,TP,2.4x6.4m
....4 R812 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R813 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R816 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
7-4 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
