Electrical Parts List
Samsung Electronics 7-5
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
....4 R817 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R818 2001-001113 R-CARBON(S);270KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R819 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6.
....4 R820 2001-001096 R-CARBON(S);2.2OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R821 2004-001891 R-METAL(S);133Kohm,1%,1/2W,AA,TP,2.5x6.5
....4 R822 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R823 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R824 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R825 2001-000066 R-CARBON(S);10KOHM,5%,1/2W,AA,TP,2.4X6.4
....4 R827 2008-000284 R-FUSIBLE(S);0.1OHM,10%,2W,AF,TP,3.9X10M
....4 R828 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm
....4 R829 2008-001029 R-FUSIBLE(S);5.6OHM,5%,2W,AF,TP,3.9X10MM
....4 R831 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R832 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R833 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R835 2003-002181 R-METAL OXIDE(S);68Kohm,5%,2W,AG,TP,3.9x
....4 R836 2003-002181 R-METAL OXIDE(S);68Kohm,5%,2W,AG,TP,3.9x
....4 R901 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R903 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R904 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R905 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R906 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R908 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R910 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R911 2001-000628 R-CARBON;300OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R912 2001-000628 R-CARBON;300OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R914 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R919 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R920 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R921 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R922 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R923 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R924 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R925 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R927 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R928 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R929 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R930 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R931 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R935 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R936 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R937 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R938 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R940 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R942 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R945 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R946 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R947 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R948 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RX801S 2002-001010 R-COMPOSITION;1.8Mohm,5%,1/2W,AA,TP,3.7x
....4 RY801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x
....4 RY802S 2002-001013 R-COMPOSITION;4.7Mohm,5%,1/2W,AA,TP,3.7x
....4 VP801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
....4 VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
....4 X201 2801-003432 CRYSTAL-UNIT;20.25MHZ,30PPM,28-AAM,13PF,
....4 X601 2801-003903 CRYSTAL-UNIT;18.432MHz,25ppm,28-AAM,12pF
....4 X901 2801-003728 CRYSTAL-UNIT;6MHz,30ppm,28-AAM,20pF,40oh
..2 AA98-00053A ASSY SUB PART;KS3A,MAIN(OPT),PAL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
..2 AA95-00840A ASSY-DYNAMIC FOCUS;-,29,100HZ,KS3A,PAL,
...3 LH01 AA26-90002C TRANS-DUMMY;-,3.5mH,EER2834,130/1200,ST
...3 LH02 AA27-40003L COIL-HORIZ.WIDTH;-,1.0mH,DR14x20,2UEW0.4
...3 PCB AA41-00152C PCB-DOUBLE FOCUS;CW29A6VN8X/XEF,FR-1,1L, S.N.A
...3 RH28 2008-001113 R-FUSIBLE(S);0.22ohm,10%,2W,AG,TP,3.9x12
...3 WIRE3 AA39-20061C LEAD CONNECTOR-ASSY;-,YFH800-03,S,3P,200
...3 AA98-00055A ASSY SUB PART;KS3A,DYNAMIC FODUS,ALL,- S.N.A
....4 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
...3 AA99-20081Q ASSY-PCB SUB,AUTO; AA95-00840A ,V S.N.A
..2 AA95-00838A ASSY PCB CRT;-,KS3A,29(100HZ),-,PAL
...3 CN501A 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
...3 CN501E AA39-20025F LEAD CONNECTOR-ASSY;-,67096-010,S,10P,50
...3 CN502E AA39-20029K LEAD CONNECTOR-ASSY;-,67096-007,S,7P,400
...3 IC501 AA96-50151B ASSY-H/S;-,AMP,AA61-10060A,TDA6111Q,-
....4 1201-001131 IC-VIDEO AMP;6111,SIP,9P,-,SINGLE,-,PLAS
....4 6001-000057 SCREW-MACHINE;RH,+,M3,L6,ZPC(BLK),SWRCH1 S.N.A
....4 6021-000222 NUT-HEXAGON;2C,M3,ZPC(YEL),SM20C 1 S.N.A
....4 AA61-10060A BRACKET-TR;-,-,CUS-1 1/2H,T0.5,-,-,- S.N.A
...3 IC502 AA96-50151B ASSY-H/S;-,AMP,AA61-10060A,TDA6111Q,-
...3 IC503 AA96-50151B ASSY-H/S;-,AMP,AA61-10060A,TDA6111Q,-
...3 ICG01 1201-000191 IC-OP AMP;4558,DIP,8P,300MIL,DUAL,20V/mV
...3 JA501 3722-001503 JACK-PIN;1P,1PI,NI,RED,SCR-JACK
...3 PCB AA41-00210C PCB-CRT;CS29A6,FR-1,1L,C,1.6T,330x245, S.N.A
...3 QF04 AA96-00111A ASSY-H/S;-,-,AA62-30013L,2SC2344,-
....4 0502-000153 TR-POWER;2SC2344-D,NPN,1.2W,TO-220,-,60
....4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
....4 AA62-30013L HEATSINK-ES;-,-,-,-,44/22,-,WHT,-,-,-,- S.N.A
...3 QF05 AA96-00111B ASSY-H/S;-,-,AA62-30013L,2SA1011,-
....4 0502-000131 TR-POWER;2SA1011-D,PNP,1.2W,TO-220,-,60
....4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
....4 AA62-30013L HEATSINK-ES;-,-,-,-,44/22,-,WHT,-,-,-,- S.N.A
...3 QG01 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
...3 R511 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
...3 R523 2008-000255 R-FUSIBLE(S);1.5ohm,5%,1W,AA,TP,3.9x10mm
...3 VA999 3704-001032 SOCKET-CRT;8P,29PI,35.5PI,AU30U
...3 AA99-20081P ASSY-PCB SUB,AUTO; AA95-00838A ,V S.N.A
....4 C502 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
....4 C503 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
....4 C505 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
....4 C506 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
....4 C508 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
....4 C509 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
....4 C510 2401-001563 C-AL;47uF,20%,400V,GP,TP,16x25,7.5
....4 C511 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5
....4 C512 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
....4 C513 2201-000723 C-CERAMIC,DISC;4.7nF,20%,3KV,Y5U,TP,16x5
....4 C514 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m
....4 C515 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
....4 C516 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
....4 C518 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C519 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C520 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C521 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C522 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C523 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C526 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
....4 CF01 2201-000180 C-CERAMIC,DISC;10nF,10%,50V,Y5V,TP,7x3,5
....4 CF02 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
....4 CF03 2201-000376 C-CERAMIC,DISC;0.22nF,5%,50V,SL,TP,6.3x3
....4 CF04 2201-000653 C-CERAMIC,DISC;0.068nF,5%,50V,SL,TP,5x3,
....4 CF05 2301-000261 C-FILM,PEF;4.7nF,5%,100V,TP,10.5x12.5x6.
....4 CF06 2201-000516 C-CERAMIC,DISC;4.7nF,+100-0%,500V,Y5U,TP
....4 CF07 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
....4 CF08 2201-000604 C-CERAMIC,DISC;0.056nF,+100-0%,500V,SL,T
....4 CF10 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 CF11 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5
....4 CF12 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
....4 CF14 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
....4 CG01 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
....4 CG02 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
....4 CG03 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
....4 CG04 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
....4 CN502A 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
....4 CNF01 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5MM,STRAIGH
....4 CNG01 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5MM,STRAIGH
....4 D502 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
....4 D507 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
....4 D508 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
....4 D509 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
....4 D510 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
....4 D511 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
....4 D512 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
....4 DF01 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 DF02 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
....4 DF03 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
....4 DF04 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 DG01 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
....4 DZ503 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
....4 DZ504 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
....4 DZ505 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
....4 DZF01 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T
