....4 DZF02 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T
....4 L501 2701-000178 INDUCTOR-AXIAL;33uH,10%,3x7mm
....4 L503 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L504 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 L505 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 LF01 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
....4 LF02 2701-000112 INDUCTOR-AXIAL;100uH,10%,3x7mm
....4 LF04 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 LF05 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
....4 Q502 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
....4 Q503 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
....4 Q504 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
....4 QF01 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 QF02 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 QF03 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO-
....4 QG02 0502-000244 TR-POWER;KSA940,PNP,1.5W,TO-220,-,40-14
....4 QG03 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6
....4 R501 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R502 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R503 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R505 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
....4 R506 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R507 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R508 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R510 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
....4 R512 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R513 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
....4 R515 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
....4 R517 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4
....4 R518 2003-002171 R-METAL OXIDE(S);150ohm,5%,2W,AG,TP,3.9x
....4 R519 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7
....4 R521 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R522 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R526 2004-000500 R-METAL;2.7Kohm,1%,1/8W,AA,TP,1.8x3.2m
....4 R527 2004-000433 R-METAL;1Kohm,1%,1/8W,AA,TP,1.8x3.2mm
....4 R542 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R543 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R544 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R546 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RF02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RF03 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RF04 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RF05 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RF06 2001-000989 R-CARBON;820KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RF07 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RF08 2001-000313 R-CARBON;11KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RF09 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RF10 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RF11 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RF12 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 RF13 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4
....4 RF14 2001-001071 R-CARBON(S);12KOHM,5%,1/2W,AA,TP,2.4X6.4
....4 RF15 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
....4 RF16 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4
....4 RF17 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
....4 RF18 2003-000458 R-METAL OXIDE(S);100ohm,5%,2W,AF,TP,4x12
....4 RF19 2003-001023 R-METAL OXIDE(S);120ohm,5%,2W,AF,TP,3.9x
....4 RF20 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
....4 RF21 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
....4 RF22 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
....4 RF23 2003-000746 R-METAL OXIDE(S);56ohm,5%,2W,AF,TP,4x12m
....4 RF24 2003-000746 R-METAL OXIDE(S);56ohm,5%,2W,AF,TP,4x12m
....4 RF25 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x
....4 RG01 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 RG02 2004-002022 R-METAL(S);51Kohm,1%,1/2W,AA,TP,2.4x6.4m
....4 RG03 2004-001987 R-METAL(S);4.3Kohm,1%,1/2W,AA,TP,2.4x6.4
....4 RG04 2004-002022 R-METAL(S);51Kohm,1%,1/2W,AA,TP,2.4x6.4m
....4 RG05 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4
....4 RG06 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
....4 RG07 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
....4 RG08 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4
....4 SG501 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
....4 SG502 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
....4 SG503 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
....4 SG504 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
ASSY TERMINAL BOARD
1 * AA91-00368C ASSY TERMINAL BOARD;-,HIPS,V0,BLK,KS3A S
..2 AA63-40254B TERMINAL-BOARD,ANT;-,HIPS HB,BLK KCT55A, S.N.A
..2 AA64-01036D INLAY BACK;29A5,PS SHEET,T0.5,-,BLK,-,SC S.N.A
ASSY CHASSIS PART
1 * AA90-30213D ASSY CHASSIS PART;KS3A,295A S.N.A
..2 AV AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M S.N.A
..2 D-FOCU 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW
..2 PM+HC 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW
..2 TB+HC 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW
..2 AA61-20254A HOLDER-CHASSIS;-,CS-622A,HIPS,V0,BLK,- S.N.A
ASSY-PCB,A/V SIDE
1 * AA95-00872A ASSY-PCB,A/V SIDE;-,29A6,29A5,100HZ,KS3A
..2 C701 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
..2 C702 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
..2 C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
..2 C704 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
..2 C705 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
..2 C706 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
..2 C707 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
..2 C708 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
..2 CN701 AA39-20068G LEAD CONNECTOR-ASSY;-,YBNH025-08,67096-0
..2 CN702 AA39-20070J LEAD CONNECTOR-ASSY;-,-,-,7P,-,-,-,YBNH2
..2 CN703 AA39-20069A LEAD CONNECTOR-ASSY;-,YBNH025-05,67096-0
..2 CN704 AA39-00070A LEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB
..2 JA701 3722-001031 JACK-RCA;3P,3.6MM,#18,AU
..2 JH701 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO
..2 JS701 3722-001163 JACK-VHS;4P,12mm,AU,BLK,N
..2 L701 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 L702 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 L703 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 L704 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 L705 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
..2 L706 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
..2 L707 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
..2 L708 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
..2 L709 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 PCB AA41-00155B PCB-SIDE AV;CS29A6,FR-1,1L,B,1.6T,245x24 S.N.A
..2 R701 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
..2 R702 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
..2 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
..2 AA63-10002A BAND-TIE;-,NYLON66 V2,-,-,L100,NTR,-,- S.N.A
ASSY-POWER,CORD
1 * AA96-20130C ASSY-POWER,CORD;-,CP2/NO(4.0R),H/C300MM,
..2 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A
..2 AA39-10003B POWER-CORD;-,KJP-140,KLCE-2F,2.4m,HOUS,S
..2 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A
ASSY PCB CONTROL
1 * AA95-00681A ASSY PCB CONTROL;-,KS3A,29A5(50HZ),PAL
..2 CN811 AA39-20179F LEAD CONNECTOR-ASSY;-,-,-,3(2)P,-,-,-,YF
..2 CNY01 AA39-20546E LEAD CONNECTOR-ASSY;-,-,-,5P,-,-,-,YBNH2
..2 CNY02 AA39-00106B LEAD CONNECTOR-ASSY;-,-,-,4P,-,-,-,YBNH2
..2 CY01 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
..2 LDY01 0601-000198 LED;ROUND,RED/GRN,5.0mm,630/565nm
..2 PCB AA41-00299B PCB-CONTROL;CS29A5WT,FR-1,1L,B,1.6T,245x S.N.A
Electrical Parts List
7-6 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
