Electrical Parts List
Samsung Electronics 7-7
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
..2 RMY01 AA59-60002B MODULE-REMOCON;-,ORC-50HF,38KHZ,940MM,ME
..2 SCREW 6001-000057 SCREW-MACHINE;RH,+,M3,L6,ZPC(BLK),SWRCH1 S.N.A
..2 SW811S 3403-000179 SWITCH-PUSH;250V,5A,DPST,-,JPW-2104B
..2 SWY02 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
..2 SWY03 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
..2 SWY04 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
..2 SWY05 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
..2 SWY06 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
..2 AA99-20083B ASSY-PCB SUB,AUTO; AA95-00681A ,V S.N.A
...3 DZY01 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
...3 DZY02 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
...3 LY01 2701-000136 INDUCTOR-AXIAL;18uH,10%,2.5x3.4mm
...3 RY01 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M
...3 RY02 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RY03 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 RY04 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 RY05 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM
..2 AA98-00056A ASSY SUB PART;KS3A,PCB,CONTROL,ALL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
ASSY CABINET FRONT
1 * AA91-00113W ASSY CABINET FRONT;-,29A5 KS3A CIS,S704+
..2 KNOPOW AA61-60005D SPRING-CS;-,SUS304,0.4,OD5.5,H9,N4,-,-,-
..2 AA64-60445V INLAY AV;29A5,PS SHEET,-,-,BLK,-,KS3A E
..2 AA64-60446C INLAY—PC,JACK;29A6,L/GRAY,PS SHEET,T0.5 S.N.A
..2 AA64-70117B BADGE-BRAND;AL,SS,SILVER,L65,R2000,-,- S.N.A
..2 AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M S.N.A
..2 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA64-40456B INDICATOR-LED;-,295A,-,ACRYL,-,CLR,-
..2 AA64-10709A KNOB-MASTER;-,295A,VT803M MASTER,ABS,HB,
..2 AA64-10710A KNOB-CONTROL;-,725A,-,ABS,HB,GRAY
..2 AA64-31106S CABINET FRONT;29A5 KS3A,S704P+G802P PLAN
..2 AA64-40455A WINDOW-REMOCON;-,725A,-,PC,-,VIOLET,-
ASSY CABINET
1 * AA90-00376D ASSY CABINET;25A6,CS29A5HT8X/BWT
..2 BRK+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR S.N.A
..2 CABBAC AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- S.N.A
..2 CB+TER AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW
..2 CF+AV 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZPC(BLK),SWR
..2 CF+CB AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW
..2 CP+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR S.N.A
..2 CRT AA63-60004G SPACER-GUM,CRT;NTR RUBBER,T3.0,GRY,-,-,- S.N.A
..2 CRT+CF AA60-10050V SCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S S.N.A
..2 CTS+CB AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW
..2 D-COIL AA65-30113A CLAMP-D,COIL;NYLON 66,V2,BLK,TVI 25~29,- S.N.A
..2 DOME AA60-10050A SCREW-ASSY;WP,RH,+,M4,L25,SWRCH18A,-,ZPC S.N.A
..2 TER+RJ 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR S.N.A
..2 AA65-30017A CLAMP-D,COIL;NYLON-66,V0,NTR,DADH300,25 S.N.A
..2 AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,- S.N.A
..2 AA61-10054A BRACKET-CRATER;-,6277,STS304,T0.5,-,-,- S.N.A
..2 AA63-10007C BAND-PP;-,-,-,W18,-,CLEAR,1G,- S.N.A
..2 AA63-30213C COVER-TOP,SPK;-,725A,-,HIPS,V2,BLK,-,- S.N.A
..2 AA64-01230B INLAY-COVER;D2,D3,PVC-SHEET,T0.4,94V0,-, S.N.A
..2 AA64-31107C CABINET-BACK;-,29A5,-,HIPS,V2,BLK,-,-
ASSY HOLDER SPK
1 * AA91-00333B ASSY HOLDER SPK;-,PP,8ohm/15W,BLK,AA91-0
ASSY-CRT
1 * AA94-01251A ASSY-CRT;A68QCP891X004(C),+380MG,29INCH
..2 AA03-00076A CRT-COLOR;-,A68QCP891X004(C),+380MG,29IN
ASSY ACCESSORY
1 * AA94-02886A ASSY ACCESSORY;CS29A5HT8X/BWT,KS3A,RUSSI S.N.A
..2 AA68-01316A MANUAL USERS;CS29A5HT8X/BWT,-,RUS,-,W/P1
..2 AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/ S.N.A
REMOCON
1 * AA59-00116A REMOCON;-,TM57,D3/D4,37,L/GRAY,S/S,EX,
