Electrical Parts List
7-8 Samsung Electronics
7-2 CZ21A8VW8X/ELS
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
ASSY PCB MAIN(OPT)
1 * AA94-02037Z ASSY PCB MAIN(OPT);CZ21A8VW8X/ELS,KS3A,A
..2 BOT 2201-000681 C-CERAMIC,DISC;0.082nF,5%,50V,SL,TP,5x3,
..2 BOT 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
..2 BOTZ 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
..2 C407 2301-001338 C-FILM,MPE-PPF;0.68nF,5%,1.6kV,TP,28x7x1
..2 C815 2401-003602 C-AL;220uF,20%,160V,GP,BK,22x25mm,1 S.N.A
..2 C820 2401-003076 C-AL;3300uF,20%,50V,WP,BK,18x35.5mm
..2 CLAMP AA65-30109A CLAMP-FBT;NYLON-66,V2,BLK,-,-,- S.N.A
..2 CLAMP AA65-30018A CLAMP-WIRE;NYLON-66,-,-,DATL-600,DONG-A, S.N.A
..2 CN501B AA39-20054B LEAD CONNECTOR-ASSY;-,YBNH025-06,S,6P,50
..2 CN502B AA39-20053A LEAD CONNECTOR-ASSY;-,YBNH025-05,S,5P,40
..2 D-COIL AA27-00130A COIL DEGAUSSING;-,-,-,-,40T,9ohm,-,21inc
..2 D801S AA96-00276A ASSY H/S;-,BRIDGE,AA62-00052A,RBV606,WA
...3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
...3 AA62-00052A HEAT SINK-PS;-,-,-,SILVER,HOLE 18.5mm, 2 S.N.A
...3 AA60-30003A WASHER;-,-,-,T1.5,-,SBHG-1,- S.N.A
...3 0402-000549 DIODE-BRIDGE;RBV606,600V,6A,-,BK
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 HC401 AA96-00275A ASSY H/S;-,COMPLEX,AA62-00051A,KSD5703,
...3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
...3 AA60-30001A WASHER-PLATE;M3,ID3.5,15X8.5,T1.0,-,SBHG S.N.A
...3 AA62-00051A HEAT SINK-PS;-,-,-,SILVER,HOLE 31mm,ALL, S.N.A
...3 0502-001136 TR-POWER;KSD5703,NPN,70W,TO-3PF,ST,8-
...3 0402-001296 DIODE-RECTIFIER;FMP-3FU,1.5KV,5A,TO-3PF,
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 HC801 AA96-00274A ASSY H/S;-,COMPLEX,AA62-00053A,FMLG12S
...3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
...3 AA62-00053A HEAT SINK-PS;-,-,-,SILVER,HOLE 22mm,ALL, S.N.A
...3 1203-001006 IC-VOLTAGE REGULATOR;78R05,TO-220F,4P,-,
...3 0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,-
...3 0402-000231 DIODE-RECTIFIER;FMG-G26S,600V,4A,TO-220F
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 IC602 AA96-50372B ASSY H/S;-,SOUND AMP,AA62-30181J,TDA726
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 1201-001308 IC-POWER AMP;7266,ZIP,15P,-,DUAL,26dB,PL
...3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
...3 AA62-30181J HEAT SINK-ES;-,AL6063 EXTR.,2,WHT,40MM,- S.N.A
..2 IC801S AA96-50373C ASSY-H/S;-,-,AA62-30181K,KA3S1265R,-
...3 AA62-30181K HEAT SINK-ES;-,AL6063 EXTR.,2,WHT,40MM,- S.N.A
...3 AA61-10386A BRACKET-IC;-,-,SECC 100,T1.0,-,KA2S0680, S.N.A
...3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
...3 1203-001482 IC-PWM CONTROLLER;3S1265R,TO-3P,5P,210,P
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 IC804 AA96-00243C ASSY H/S;-,REGULATOR,AA62-00045A,KA7806
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 1203-000284 IC-POSI.FIXED REG.;7806,TO-220,3P,-,PLAS
...3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
...3 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, S.N.A
..2 IC901 AA09-00041A IC-MCU;SDA555X-OTP,SDA555X-OTP,-,-,52
..2 JA701 3722-000195 JACK-SCART;42P,-,SN,BLK,NO
..2 S-H/S AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 T444S AA26-00057A TRANS-FBT;-,FUH-29A001B(S),25/29,130
..2 T801S AA26-00044C TRANS SWITCHING;CODE-NO,CT-21A8,-,AC90~2
..2 TUBE AA39-00108A LEAD CONNECTOR-ASSY;,-,-,-,-,-,-,GRT-TUB
..2 AA61-00462B SUPPORT-HEAT SINK;21A9,ABS,GRAY,VO,-,-,- S.N.A
..2 AA98-00053A ASSY SUB PART;KS3A,MAIN(OPT),PAL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
..2 AA99-30186Z ASSY-PCB ROBOT; AA94-02037Z ,ER S.N.A
...3 C405 2306-000327 C-FILM,MPPF;6.3nF,3%,1.6KV,TP,28.5x18x10
...3 C406 2306-000327 C-FILM,MPPF;6.3nF,3%,1.6KV,TP,28.5x18x10
...3 C423 2306-000235 C-FILM,MPPF;560nF,5%,400V,TP,26*22.5*14,
...3 C426 2306-000195 C-FILM,MPPF;360nF,5%,400V,TP,26x19x11.5,
...3 C803 2401-003025 C-AL;330uF,20%,400V,GP,ST,30x40,10
...3 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
...3 CX802S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
...3 CY802S 2201-002002 C-CERAMIC,DISC;4.7nF,20%,400V,Y5U,TP,16x
...3 FP801S 3601-000297 FUSE-CARTRIDGE;250V,5A,TIME-LAG,GLASS,5.
...3 IC201S 1204-001633 IC-VIDEO PROCESS;VDP3112B-C3,DIP,64P,709
...3 IC301 AA96-50406A ASSY-H/S;-,-,AA62-30180K,LA7845,-
....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
....4 1204-000517 IC-VERTIVAL DEF.;LA7845,SIP,7P,-,PLASTIC
....4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
....4 AA62-30180K HEAT SINK-ES;-,A6063 EXTR,-,WHT,50/13,-, S.N.A
...3 IC401 1202-000103 IC-VOLTAGE COMP.;393,DIP,8P,300MIL,DUAL,
...3 IC501 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS
...3 IC502 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS
...3 IC503 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS
...3 IC601 1204-001775 IC-SOUND PROCESSOR;MSP3410D-C5 9458 ,SDI
...3 IC803 1203-001697 IC-VOLTAGE REGULATOR;78R08,TO-220,4P,-,P
...3 IC902 1103-001171 IC-EEPROM;L51DC,16KBit,DIP,8P,300MIL,10m
...3 L403 AA27-00101A COIL LINEARITY;58uH,58uH,DR14x15 C:6.0,1
...3 L405 AA27-00096A COIL HORIZ. WIDTH;-,10.0mH,DR15 X 27.5,U
...3 L408 AA27-00097A COIL HORIZ. WIDTH;-,700uH,DR15 X 27.5,US
...3 L808 AA27-00098A COIL CHOKE;-,-,24uH,10%,-,0.1,3.0A,DR10X
...3 LD901 AA96-00461A ASSY LED GUIDE;-,-,SL-255D,RED/GRN
...3 LX801S AA29-30002N FILTER-LINE NOISE;-,16MH,1.5A,AC100~260V
...3 LX802S AA29-30002N FILTER-LINE NOISE;-,16MH,1.5A,AC100~260V
...3 NT802S 1404-001045 THERMISTOR-NTC;4.7OHM,15%,2900K,35.0MW,T
...3 PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST
...3 PT801S 1404-001156 THERMISTOR-PTC;9OHM,+30%/-20%,220VRMS,27
...3 RM901 AA59-60001U MODULE-REMOCON;-,ORC-50VF/SR-12V,38KHz,9
...3 SW801S 3403-000179 SWITCH-PUSH;250V,5A,DPST,-,JPW-2104B
...3 T401 AA26-50001L TRANS-HORIZ.DRIVE;-,29mH,133uH,4.5uH,EI2
...3 TU01S AA40-00015A TUNER-F/S;TCPW3001PD09A(S),PAL/SECAM,TR,
...3 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,-
...3 AA99-10182Q ASSY-PCB MAIN,AUTO; AA99-30186Z ,V S.N.A
....4 C102 2401-001513 C-AL;47uF,20%,16V,WT,TP,5x11,5
....4 C103 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
....4 C104 2401-003578 C-AL;1000uF,20%,10V,GP,TP,8x20mm,5
....4 C105 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
....4 C106 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5
....4 C113 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V
....4 C115 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C116 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C201 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
....4 C202 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C205 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C208 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
....4 C211 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
....4 C212 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
....4 C213 2301-000247 C-FILM,PEF;33nF,5%,50V,TP,8.1x4.5x13mm,5
....4 C214 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C215 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C216 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
....4 C217 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
....4 C218 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C219 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C220 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C221 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C222 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C223 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C224 2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
....4 C225 2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
....4 C228 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
....4 C229 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
....4 C230 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
....4 C231 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
....4 C232 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
....4 C233 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C234 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C235 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C236 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
....4 C237 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
....4 C244 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C245 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C248 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C250 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
....4 C301 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
....4 C302 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
....4 C303 2201-002103 C-CERAMIC,DISC;0.015nF,5%,500V,NP0,TP,6.
