....4 R828 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm
....4 R829 2008-001029 R-FUSIBLE(S);5.6OHM,5%,2W,AF,TP,3.9X10MM
....4 R831 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R832 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R835 2003-002211 R-METAL OXIDE(S);91Kohm,5%,2W,AG,TP,3.9x
....4 R836 2003-002211 R-METAL OXIDE(S);91Kohm,5%,2W,AG,TP,3.9x
....4 R901 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R903 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R904 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R905 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R906 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R908 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R910 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R911 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R912 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R914 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R915 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R916 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R917 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R918 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R919 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R920 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R921 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R922 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R923 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R924 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R925 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R927 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R928 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R929 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R930 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R931 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R932 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R933 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R934 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R935 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R937 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R940 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R942 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R943 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R945 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R946 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
....4 R947 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R948 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 RR430S 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
....4 RX801S 2002-001010 R-COMPOSITION;1.8Mohm,5%,1/2W,AA,TP,3.7x
....4 RY801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x
....4 RY802S 2002-001013 R-COMPOSITION;4.7Mohm,5%,1/2W,AA,TP,3.7x
....4 SG501 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
....4 SG502 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
....4 SG503 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
....4 SW901 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW902 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW903 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW904 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 SW905 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
....4 VP801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
....4 VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
....4 X201 2801-003432 CRYSTAL-UNIT;20.25MHZ,30PPM,28-AAM,13PF,
....4 X601 2801-003903 CRYSTAL-UNIT;18.432MHz,25ppm,28-AAM,12pF
....4 X901 2801-003728 CRYSTAL-UNIT;6MHz,30ppm,28-AAM,20pF,40oh
..2 AA39-20010B LEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,500
..2 AA65-30009A CLAMP-FBT;ABS,V0,BLK,-,-,- S.N.A
..2 AA65-30105B CLAMP-WIRE;NYLON 66,V2,NTR,25MM,ALL MODE S.N.A
ASSY CABINET FRONT
1 * AA91-00327W ASSY CABINET FRONT;-,21A8,(SPK)S907P+D00
..2 CF+KN 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 KNPOW AA61-60003J SPRING-CS;-,SUS304,0.5,OD6,H12,N7,-,-,-
..2 SPK+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
..2 WIN+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 AA64-70123A BADGE-BRAND;AL,SAMSUNG,SILVER,L=50,FLAT,
..2 AA64-00818B INDICATOR LED;-,21A8,-,ACRYL,-,CLR,-
..2 AA96-00358E ASSY SPEAKER;-,8ohm,5W,3001-000274,400/6
...3 3001-000274 SPEAKER;5W,8ohm,90dB,160Hz
...3 AA39-00102S LEAD CONNECTOR ASSY;-,-,-,4P,-,-,-,35155
..2 AA65-30105A CLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE S.N.A
..2 AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M S.N.A
..2 AA61-40113A STOPPER-PCB;501H,HIPS,NTR,HB,-,-
..2 AA64-00810E CABINET FRONT;21A8,SV907P+DB004P MLP,HIP
..2 AA64-00812B KNOB CONTROL;-,21A8,-,ABS,HB,G3676
..2 AA64-00814B KNOB POWER;-,21A8,-,ABS,HB,G3676
..2 AA64-00816B WINDOW REMOCON;-,21A8,-,PC,V0,VIOLET,-
ASSY-POWER,CORD
1 * AA96-20109A ASSY-POWER,CORD;-,CP2/NO(4.0),H/C400,KKP
..2 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A
..2 AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P, S.N.A
..2 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A
ASSY-PCB,A/V SIDE
1 * AA95-00790A ASSY-PCB,A/V SIDE;-,CZ21A8,KS3A,PAL,-,-
..2 BOT 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
..2 C701 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
..2 C702 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
..2 C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
..2 C704 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
..2 C705 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
..2 C706 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
..2 CN701 AA39-20068B LEAD CONNECTOR-ASSY;-,YBNH025-08,67096-0
..2 CN703 AA39-20069D LEAD CONNECTOR-ASSY;-,YBNH025-05,67096-0
..2 CN704 AA39-00070A LEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB
..2 CN705 AA39-20009D LEAD CONNECTOR-ASSY;-,YFH800-01,-,1P,500
..2 JA701 3722-001031 JACK-RCA;3P,3.6MM,#18,AU
..2 JH701 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO
..2 L701 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 L702 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 L703 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 L704 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
..2 L707 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
..2 L708 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
..2 PCB AA41-00267B PCB-SIDE A/V;CW6844,FR-1,1L,B,1.6T,245x2 S.N.A
..2 R701 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
..2 R702 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
..2 AA63-10002A BAND-TIE;-,NYLON66 V2,-,-,L100,NTR,-,- S.N.A
..2 AA98-00057A ASSY SUB PART;KS3A,PCB,A/V SIDE,ALL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A
ASSY CRT
1 * AA94-02768A ASSY CRT;A51QDJ279X14,+300MG,21FLAT,IT S.N.A
..2 AA03-00189A CRT COLOR;A51QDJ279X14,21DF,21INCH,0.75m
ASSY CABINET
1 * AA90-00369R ASSY CABINET;21A8,CZ21A8VW8X/ELS S.N.A
..2 AV+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL)
..2 BACK AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- S.N.A
..2 CB+CF AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW
..2 CB+JCK 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
..2 CF AA61-00438B BOSS-CRT;21A8.9,HIPS,HB,NTR,-,-,- S.N.A
..2 PCB AA64-01230B INLAY-COVER;D2,D3,PVC-SHEET,T0.4,94V0,-, S.N.A
..2 AA65-30008A CLAMP-CORD;PE,HB,BLK,-,-,- S.N.A
Electrical Parts List
7-12 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
