Samsung DMR57LFS/XAA User Manual

3-5
3. Disassembly and Reassembly
Part Photo Description
Drain Pump
1. Place the dishwasher on its back so that you can
see the base. Remove the two (2) screws that hold
the base and the shutter in place.
2. Remove the leakage sensor connector (white) in the
shutter.
3. Disconnect the two (2) drain pump connectors.
4. Remove the drain pump by rotating it
counterclockwise.
When removing the drain pump, lift up the hook
holding it in place slightly and then rotate it so that
the hook is not damaged.
