6-7
6. PCB Diagram
6-7. Detailed Specications and Descriptions for Connectors (TOUCH 3KEY - DMR77,DMR78)
PIN DESCRIPTIONS ሪ
1. KEY6
2. KEY7
3. KEY_Signal_1
4. KEY_Signal_2
5. DC 5V
6. DC GND
Half Load Sanitize Delay Start
