► MODEL CODE: DMR77***, DMR78***
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
SVC_
Code
Code No. Description Specication QTY
SA/
SNA
Remark
F110 DD63-00066A CUSHION-DUCT(L) DM1477,PU-FORM,-,-,-,-,R 1 SA
F200 DD63-00059A ABSORBER-
SOUND(FRONT)
DM1477,FELT,T10,W5 1 SA
F085 DD61-00203A BRACKET-COVER FAN DM1477,STS304,T0.5,-,- 1 SA
F075 DD61-00205A BRACKET-DOOR LINK DM1477,GI,T0.8,-,-,-,R 1 SA
F222 DD97-00104A ASSY-PANEL CONTROL DM1477,R-PJT/SIL 1 SA
F111 DD63-00094A CUSHION-DUCT(R) DM1477,PU-FORM,-,-,-,-,R 1 SA
F083 DD63-00065A COVER-FAN DM1477,POM,-,-,-,-,-,GRY,R-PJT 1 SA
F219 DD97-00103A ASSY-DOOR DM1477,R-PJT 1 SNA DMR77LHS
D049 DD97-00139A ASSY-DOOR DMR77LHB,BLACK FRAME FRONT 1 SNA DMR77LHB
D049 DD97-00140A ASSY-DOOR DMR77LHW,WHITE FRAME FRONT 1 SNA DMR77LHW
D049 DD97-00103B ASSY-DOOR DMR78,-,R2-PJT 1 SNA DMR78AHS
D049 DD97-00103C ASSY-DOOR DMR78AHB,R2-PJT 1 SNA DMR78AHB
D049 DD97-00103D ASSY-DOOR DMR78AHW,R2-PJT 1 SNA DMR78AHW
F074 DD64-00046A DOOR-LINK(R) DM1477,EGI,T3.0,-,-,-,BLK,R 1 SA
F073 DD64-00047A DOOR-LINK(L) DM1477,EGI,T3.0,-,-,-,BLK,R 1 SA
D019 DD64-00043A HANDLE-DOOR DM1477,AL,T2.0,-,L572,-,-,R-PJT 1 SA DMR77LHS
D019 DD64-00043B HANDLE-DOOR DMR77LHB,AL,T2.0,-,L572,-,BLK,R-PJT 1 SA DMR77LHB
D019 DD64-00043C HANDLE-DOOR DMR77LHW,AL,T2.0,-,L572,-,WHT,R-PJT 1 SA DMR77LHW
D019 DD64-00060A HANDLE-DOOR DMR78,STS430,1.0mm,-,-,-,-,- 1 SA DMR78AHS
D019 DD64-00060B HANDLE-DOOR DMR78,STEEL,1.0mm,-,-,-,BLACK,- 1 SA DMR78AHB
D019 DD64-00060C HANDLE-DOOR DMR78,STEEL,1.0mm,-,-,-,WHITE,- 1 SA DMR78AHW
F100 DD67-00038A FAN-VENT DM1477,PP,-,-,-,R-PJT 1 SA
F060 DD62-00049A SEAL-VENT DM1477,EPDM,BLK,-,-,-,R-PJT 1 SA
F223 DD61-00201A FRAME-FRONT DM1477,STS304,-,-,-,T0.8,W601,L743,R-PJT 1 SA DMR77LHS
F223 DD61-00201B FRAME-FRONT DMR77LHB,EGI,-,-,BLK,T0.8,w601,L743,R-PJT 1 SA DMR77LHB
F223 DD61-00201C FRAME-FRONT DMR77LHB,EGI,-,-,BLK,T0.8,w601,L743,R-PJT 1 SA DMR77LHW
F223 DD61-00201D FRAME-FRONT DMR78,STS430,-,-,-,0.8,601,743,R2-pjt 1 SA DMR78AHS
F223 DD61-00201E FRAME-FRONT DMR78AHB,STS430,T0.8,W601,L743,R2-
PJT
1 SA DMR78AHB
F223 DD61-00201F FRAME-FRONT DMR78AHW,STS430,WHITE,T0.8,W601,L7
43,R2-PJT
1 SA DMR78AHW
G076 DD61-00207A GUIDE-DOOR LINK DM1477,POM,-,-,-,WHT,R-P 2 SA
F220 DD61-00200A GUIDE-HANDLE DM1477,ABS,-,-,-,BLK,R-PJT 2 SA DMR77LHS
D032 DD61-00200B GUIDE-HANDLE DMR77LHB,ABS,-,-,-,BLK,R-PJT 2 SA DMR77LHB
D032 DD61-00200C GUIDE-HANDLE DMR77LHW,ABS,-,-,-,WHT,R-PJT 2 SA DMR77LHW
F197 DD61-00243A HOLDER-BOLT DM1477,MSWR,OD20,ID5.5,T2.0, 2 SA
M024 DD31-00006A MOTOR VENTILATION -,DM1477,-,-,-,120V,30 1 SA
F198 DD62-00045A SEAL-GUIDE LED DM1477,EPDM,BLK,-,-,-,R-P 1 SA
F199 DD62-00047A SEAL-GUIDE LED(F) DM1477,EPDM,BLK,-,-,-, 1 SA
F175 DD62-00044A SEAL-FAN DM1477,EPDM,BLK,-,-,-,R-PJT 1 SA
F136 DD60-00001A SPACER-DOOR LINK DM1477,POM,-,-,-,WHT,-, 2 SA
F132 DD34-00002B SWITCH DOOR-LOCK -,Normal open,-,125VAC/ 1 SA
F140 DD97-00106A ASSY-TUB FRONT DM1475,R-PJT 1 SA
F151 DD67-00037A DUCT-CONDENSER DM1477,PP,-,-,-,BLK,R-PJT 1 SA
F219 6011-001640 BOLT-HEX M5,L45,ZPC(YEL),SWRCH18A,- 2 SA DMR77series
F093 6011-001805 BOLT-HEX M5,L15,ZPC(YEL),SWRCH18A,- 2 SA DMR78series
F221 DD64-00041A WINDOW-PANEL FRONT DM1477,PC,-,-,-,-,CLE 1 SA
F184 DD59-01001A DISPENSER-RINSE -AID 100418,-,-,120V/60H 1 SA
F131 DD61-00103A BRACKET-DISPENSOR SDW-H120,GI,T0.8,-,-,- 2 SA
5.2-0 DD97-00107A ASSY-CONDENSING DM1477,R-PJT 1 SNA
F164 DD97-00147A ASSY-CASE VENT DMR77LHS,R-PJT 1 SA
F156 DD81-01151A SCREW-DOOR(S) DMR,SUSXM7,T20,4x17,672000 8 SA
F185 DD81-01152A SCREW-DOOR(M) DMR,SUSXM7,T20,4x25,672000 2 SA
F109 DD81-01153A SCREW-DOOR(L) DMR,SUSXM7,T20,4x41,672000 2 SA
C003 DD92-00008A ASSY PCB DMR,LED,-,-,HIDDEN,-,-,-,- 1 SA
