Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-113-11
Disassembly and reassembly
Fig 3-20
(b) Remove the PCB FPC-CCD ASSY.
PCB FPC-CCD ASSY
SCREW-TAPTYPE
SCREW-TAPTYPE
(a) Remove the ve SCREWs.
SCREW-TAPTYPE
Fig 3-21
2. Disassembly of BARREL FPCB.
