Samsung DV448AEP - Door Removal; Frame Front Removal

Disassembly and Reassembly _ 13
Part Figure Description
Door Removal
7. RemovetheSupport-Hinge,Hinge-Door,Guide
HolderGlass,DoorGlassandDoorSeal.
 A.BecarefulnottoscratchtheCoverDoor.
 B.BecarefulofthedamagetotheDoorGlass.
 C.ChecktheDoorSealconditionafterthe
assembly.
Frame Front
Removal
1. Disconnectthepowersupplytotheunit.
2. RemovethePanelControl,theMainPCBandthe
Cover Top.
3. Remove4screwsfromtheFrameFront.
 When2screwsofthetopportionworkbecause
wasaddednewly,keepinmind.
5. Remove3screws.
6. RemovetheDoorSwitchHousing.
 WhenreassembleDoorSwitchtoFrameFront,
becarefulforinsertdirection.
7. LifttheFrameFrontoffthethreetabsacrossthe
bottomandremove.
