Samsung DV448AEP - Model Code: DV5471 AGP;XAA

44 _ Exploded views and Parts list
MODEL CODE: DV5471AGP/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un SA/SNA
0 DV5471AGP/XAA ASSY CLOTHES DRYER ORCA-DRYER
1 DC97-16739A ASSY FRAME ORCA-DRYER,DV5471AEP/XAA,INOX 1 PC SA
1-1 DC97-16750A ASSY BRACKET SPRING(L) ORCA-DRYER,DV5471AEP/XAA 1 PC SA
1-2 DC61-03047A BRACKET-SPRING(R) ORCA-DRYER,EGI-
SECC,W66.5,L643.8,NTR,DV55A7S2P
1 PC SNA
2 DC63-00534B COVER-BACK WINGS-DRYER,GI,T0.6,-,-,-,-,NTR,- 1 PC SA
5 DC61-03127A GUIDE-COVERTOP ORCA,POM,W28.0,L23.0,K300,BLK,OR
CA-PJT
4 PC SA
6 DC90-06598A ASSYCOVERTOP ORCA-DRYER,DV5471AEP/XAA 1 PC SNA
6-1 DC63-01360A COVER-PCB(M) DV5471AEP,ABS,T2.5,NTR,VE-0858 1 PC SNA
6-2 DC67-00607A CAP-COVERTOP DV5471AEP/
XAA,ABS,T2.5,W65.2,L105.0,VE-
0856,NTR
1 PC SNA
6-3 DC92-00322E ASSY PCB MAIN ORCA,DRYER
MAIN,120V/60Hz,Y,SMPS,TNY277
1 PC SA
6-4 DC97-16751A ASSYCOVERTOP ORCA-DRYER,DV5471AEP,EGI,T0.8,W
684.0*L714.2,INOX
1 PC SA
6-4-1 DC63-01325A COVER-TOP DV5471AEP,EGI-
SECC,T0.8,W684.0,L714.2,INOX
1 PC SA
6-4-2 DC61-03134A BRACKET-COVERTOP DV5471AEP,GI-
SGCC,T1.4,W45.0,L24.0,BLACK
2 PC SNA
6-4-3 6002-000520 SCREW-TAPPING TH,+,-
,2,M4,L12,ZPC(WHT),SWRCH18A,-
2 PC SA
7 DC93-00191B ASSY M. WIRE HARNESS ORCA,DRYER,120,DC
LAMP,STEAM,GAS
1 PC SNA
8 DC90-06951A ASSY PANEL CONTROL ORCA-DRYER,DV5471AGP/XAA 1 PC SNA
9 DC97-16755A ASSY DOOR ORCA-DRYER,DV5471AEP/XAA,INOX 1 PC SNA
10 DC97-16756A ASSY FRAME FRONT ORCA-DRYER,DV5471AEP/XAA,INOX 1 PC SNA
11 DC97-16757A ASSYDRUMFRONT ORCA-DRYER,DV5471AEP/XAA 1 PC SNA
12 DC97-16758A ASSYDRUMWRAPPER ORCA-DRYER,DV5471AEP/XAA 1 PC SNA
13 DC97-16789A ASSYDRUMBACK ORCA-DRYER,DV5471AGP/XAA 1 PC SNA
14 DC90-06576A ASSYMOTORDUCT ORCA-DRYER,DV5471AEP/XAA 1 PC SNA
15 DC97-07519A ASSYDUCTEXHAUST WINGS-DRYER,MDE9700AYW,-,-,- 1 PC SA
17 DC97-12150A ASSY LEG MARS-PJT,DRYER,-,-,-,- 4 PC SA
17-1 DC61-01226A BRACKET-LEG WINGS-DRYER,SGCC(GI),T1.6,-,-,-,- 1 PC SA
17-2 DC61-01693A LEG MARS-PJT,FRPP,-,-,-,- 1 PC SA
18 DC97-15103A ASSY CONNECTOR DV448AEW,-,PACKING/HOSE
CONNECTOR,-,-,-
1 PC SA
18-1 DC62-40178B SEAL-WATER DV338,EPDM,T3.0,ID13.5,OD24.5,HOS
E-WATER
1 PC SA
18-2 DC67-00324A HOSE-CONNECTOR DV448AEG/XAA,BRASS,ID18,OD26.5,T
5.0,L60,NTR,-
1 PC SNA
19 DC97-15249A ASSY HOSE CONNECTOR DV448AEW,-,STEAM/CONNECTOR,-,-,- 1 PC SA
20 DC97-15692A ASSY HOSE WATER ACE,WF419AAW,COLD,L1240,OD15,
ID8.7,BLK
1 PC SA
20-1 DC62-00075B HOSE-WATER(C) NBR+NYLON,ID10.2,OD16.5,L1240,BLK
,WSLS1100A0WW/COLD
1 PC SNA
20-1-1 DC62-40178A SEAL-WATER EPDM,BLK,ID12XOD25XT3 1 PC SA
20-2 DC62-40178A SEAL-WATER EPDM,BLK,ID12XOD25XT3 2 PC SA
21 DC97-10720A ASSYDUCT MDG9700AWW,-,-,-,GAS,- 1 PC SA
22 DC97-14492A ASSYBURNER -,-,-,- 1 PC SA
23 DC96-00038G ASSY POWER CORD DV4006,EP3(16A)DRYER,-,- 1 PC SA
